PH11 Biogas Storage Tank With Double Membrane Gas Holder
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden |
| Delivery Time: | 10-30 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W |
| Corrosion Resistance: | Suitable For Waste Water Salt Water, Sea Water, High Sulfur Crude Oil, Salt Fox, Organic And Inorganic Compounds | Tank Body Color: | Dark Green / Can Be Customized |
| Steel Grade: | ART 310 | Roof Available: | Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof |
| Corrosion Integrity: | Excellent | Foundation: | Concrete Or Glass Fused Steel |
| High Light: | PH11 Biogas Storage Tank,Double Membrane Gas Biogas Storage Tank,Glass Fused Steel Biogas Storage Tank |
||
Product Description
Best Biogas Tank With Double Membrane Gas Holder
The biogas produced by the anaerobic digestion unit is composed of combustible gas methane (50-75%), carbon dioxide (25-50%), water (H2O), nitrogen (N2), oxygen (O2), hydrogen sulfide (H2S), ammonia ( NH3) and trace elements (organic halogenation, siloxane, etc.). H2S, CO2 and water make biogas highly corrosive.
Whether you are fighting against greenhouse gases or rising energy costs, let Center Enamel help you build a durable anaerobic digester. We provides the best defense against of storage tanks the highly corrosive digestive process that will test the limits of any storage tank technology.
Why use Glass fused to Steel Biogas holding Tank for biogas storage tank ?
1. Advanced technology and innovative edge protection ensure Center Enamel Glass-Fused-to-Steel Tanks are the exceptional solution in most harshest storage environment.
2. Center Enamel Glass-Fused-to-Steel tanks with superior corrosion resistance can be utilized in both the liquid and gaseous zone, and maximizing the service life of tank structure.
3. Customized colors make the tank harmonized with the surrounding environment.
4. Long service life glass coating requiring minimal maintenance, reducing the risk & loss of project shutdown during operation.
5. Modular bolted constructure give shorter installation period with simple installation tools.
6. Tank can be dismantled and rebuilt, gives continuous asset value to the product.
Glass fused to Steel Biogas holding Tank Specifications
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater saltwater, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
Glass fused to Steel Biogas holding Tank Manufacturer
Center Enamel Co., Ltd is not only the first Glass fused to SteelBiogas holding Tank manufacturer and supplier in China, but also the most experienced Glass fused to Steel Biogas holding Tank manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2021, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 80 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Glass fused to Steel Biogas holding Tank Project References
