With more than 30 years of experience in the storage tank industry, Center Enamel independently develops epoxy resin tan

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: J2016012306
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number J2016012306
Acid And Alkalinity Proof: Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14 Usage: Waste Water Treatment , Sewage Treatment, Effluent Treatment, Ect.
Corrosion Resistance: Excellent ! Suitable For Waste Water Salt Water, Sea Water, High Sulfur Crude Oil, Salt Fox, Organic And Inorganic Compounds Spark Test: >1500 V
Service Life: Over 30 Years Capactiy Available: 20 M3 To 18,000 M3
PH Range: A Grade Sheet PH:3-11, AA Grade Sheet PH : 1-14

Product Description

Shijiazhuang Zhengzhong Technology Co., Ltd. is a comprehensive high-tech enterprise whose main business is the R&D, manufacturing and sales of enamel assembly tanks, environmentally friendly diversified equipment, and the undertaking of environmentally friendly EPC projects and anaerobic process sections. The company's business covers food waste, landfill leachate, municipal sewage, biogas projects, aquaculture industry, industrial sewage, petrochemicals, metallurgy and other fields. It specializes in providing customers with comprehensive services such as engineering design, equipment R&D and manufacturing, installation and commissioning, and engineering construction.

Center Enamel is innovation-oriented and continues to lead the innovation of equipment technology. It empowers the intelligent manufacturing of diversified equipment with its innovative research and development technology of enamel assembly tanks, and develops a series of environmentally friendly and diversified equipment suitable for all walks of life. It also integrates years of technology accumulation and resource accumulation. The advantages extend to the field of environmentally friendly EPC engineering, building an entire industrial chain from enamel assembled tanks to diversified equipment, environmentally friendly engineering, and anaerobic process sections. Relying on advanced R&D technology and high-quality service system, the company has successfully ranked among the well-known enterprises in the environmental protection industry, becoming the leader in the enamel assembled tank industry in Asia, an intelligent manufacturer of diversified environmental protection equipment in China, and a high-quality service provider in environmental protection EPC and anaerobic process sections. .



With more than 30 years of experience in storage tank R&D, production and construction, Center Enamel has jointly developed fusion-bonded epoxy coating technology with AkzoNobel, the world's leading paint and coatings manufacturer. Epoxy coating is an advanced anti-corrosion coating with excellent corrosion resistance and adhesion. In addition, the epoxy coating technology also adopts a special construction process - electrostatic spraying technology, which improves the uniformity and adhesion of the coating, thereby effectively extending the service life of the tank.



Epoxy resin tanks formed using epoxy coating technology are not only technologically advanced and cost-effective, but also easy and fast to install. Their quality meets the requirements of AWWA D103-09 and ISO 9227 / ASTM B117. They have been recognized by customers as soon as they were launched.



Application Test Standard Result
Coating Color Standard RAL 5015 sky blue Other colors are available
Dry Film Thickness Average Dry Thickness 5~10 miles /125 ~250 microns(internal)
5~10 miles /125 ~250 microns(epoxy primer+ topcoat)
Holiday Test ≥1100V (all panels) Zero-discontinuity at test voltage
Hot water immersion 90 days, 70° AWWA C550-05 Meets/exceeds standard
Corrosion Resistance Salt Spray ISO 9227/ASTM B117 Pass
Impact Resistance ASTM D2794 Pass 160 in-ibs direct & reverse impact
PH Range 3~12
Abrasion Resistance Adhesion ASTM D3359 Adhesion ASTM D3359
Hardness ISO15184 / ASTM D3363 2H
Chemical Immersion test 50% NaOH, 50% H2S04 Meets/exceeds industry standard
UV Resistance outdoor exposure testing 5 years
Color Stability outdoor exposure testing 5 years



inner coating

Our epoxy is one of the most durable epoxy coatings compared to other epoxies available on the market.

High voltage testing is performed on each sheet to ensure there are no defects under the test voltage.

Optimal control of exterior coating overspray enables interior coatings to comply with drinking water regulations.

Coatings undergo and must pass many different types of tests to ensure high performance and compliance with international quality standards.

Interior surfaces are factory electrostatic powder coated, providing high quality and a consistent even finish.



outer coating

The exterior coating is a combination of epoxy primer and ultra-durable polyester topcoat.

The outer coating undergoes and must pass many different types of tests to ensure high performance and compliance with international quality standards.

The formulation adheres to appropriate controls on substances, allowing the coating to achieve the highest global safety and environmental performance certifications.



From being the leader in Asia's enamel assembly tank industry to being an intelligent manufacturer of environmentally friendly diversified equipment in China, Genzon Technology has used key core technologies to continue iterative upgrades in equipment research and development to promote sustained and high-quality development of the company's business under the new situation. With the existing brand, technology and team advantages, the company will continue to focus on the forefront of industry technology, adhere to the diversified development strategy, and while promoting the environmental protection business to a new level, we will jointly paint a beautiful picture of green waters and green mountains.
