ART 310 Convenient Installation Durable Commercial Water Tanks
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden |
| Delivery Time: | 10-30 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W |
| Corrosion Integrity: | Excellent | Steel Plates Thickness: | 3mm To 12mm , Depends On The Tank Structure |
| Size Of Panel: | 2.4M * 1.2M | Easy To Clean: | Smooth, Glossy, Inert, Anti-adhesion |
| Feature: | Eco-friendly, Durability | Steel Grade: | ART 310 |
| High Light: | ART 310 Commercial Water Tanks,Anti Adhesion Commercial Water Tanks,BSCI Commercial Water Tanks |
||
Product Description
Convenient Installation Durable commercial water tanks
Zhengzhong technology commercial water tank is made of enamel steel plate, which is strong and durable, and is available in various colors. The storage tank capacity ranges from 20m³ to 25000m³. All water tanks comply with NSF61 standards, making them ideal for all commercial and industrial applications.
Our commercial water tanks are very suitable for fire fighting water, drinking water storage, commercial rainwater collection, rainwater retention, and treated water storage in the industrial, mining and agricultural sectors.
Bolted Steel Industrial Water Tanks combines the strength and flexibility of steel and outstanding corrosion resistance of glass, which providing many advantages over standard epoxy coated or welded painted storage tanks.
Center Enamel has more than 30 years experience in Bolted Steel Industrial Water Tanks design, manufacture and installation. Bolted Steel Industrial Water Tanks show good chemical and physical performance because it contains titanium. Furthermore, the superfine glass foam-like structure of the enameling layer, enable the materials’ excellent flexibility and durability.
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance |
excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds
|
Bolted Steel Industrial Water Tanks has become the premium water and liquid storage solution as below reasons:
1. Great volume: wide range of capacity of selection up to 20,000 m3.
2. Easy installed, expanded, dismantle, removed: The modular system allows not only fast rapid installation, expand, or removed not subject to any weather, but also easily repaired.
3. Strong abrasion / corrosion resistance (PH1- 14 resistance): The strong bonding enamel coating not only can prevent the corrosion of tank, but also resistance to strong acid and strong alkali.
4. Suitable for various kind of fields: Not only industrial effluent /Wastewater, sewage treatment, it also can be sued in power and energy, agriculture storage tanks, biogas digester.
5. Low project cost: as short construction, installed, the cost is much lower then other traditional tanks.
6. Long life service: More then 30 years service life.
Bolted Steel Industrial Water Tanks Application fields
Municipal: drinking water, municipal waste leachate storage, sewage treatment, wastewater treatment and anaerobic digestion
Industrial: industrial effluent storage and process, industrial effluent digestion, process water storage and bulk solids storage
Agricultural: slurry storage, farm biogas production and grain and forage silos
Mining: Diesel, Kerosene, Coal storage, Fly ash silo, and so on.
Biofuels: Biogas digester, Biogas biomass,.anaerobic reactor, aerobic reactor.
Bolted Steel Industrial Water Tanks Project References
