Chemical Resistance Bolted Steel Tanks For PH Balancing In Industrial Wastewater Project

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20161227016
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 10-30 days after deposit received
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W20161227016
Impact Resistance: Outstanding Warranty Period: 2 Years
Tank Body Color: Dark Green / Can Be Customized Foundation: Concrete Or Glass Fused Steel
Corrosion Integrity: Excellent Chemical Resistance: Excellent
High Light:

fixed roof storage tank

,

municipal water storage tanks

Product Description

Bolted Steel Tanks For PH Balancing Tanks In Industrial Wastewater Project



Bolted steel tanks are a convenient storage solution for PH balancing tanks in industrial wastewater project. They are constructed from individual steel panels that are manufactured and finished at an enclosed facility, then transported to the site and bolted together using the appropriate gaskets and fasteners for the product that will be stored. Unlike conventional concrete or welded storage solutions, which require extensive fabrication and finishing processes onsite, bolted tanks offer quick installation, lower shipping costs, and they can be assembled in nearly any type of weather, eliminating many weather-related delays.



All our bolted steel tanks are made of Glass-Fused-to-Steel, so we also call it Glass-Fused-To-Steel tanks. Glass-Fused-To-Steel is a unique tank finish. Tow materials are fused together to achieve the best of both materials – the strength and flexibility of steel combined with the corrosion resistance of glass. Applied to both interior and exterior surfaces, Steel panels baked to 840° Celsius creating the ultimate fusion of materials for a highly durable surface bond. As the panels are bolted together, it will not take that long construction times. Your investment will get the k return for minimal maintenance cost Bolt systems commonly used by others are prone to damaging the glass fused coating at the edges of a bolt hole, creating vulnerabilities in the fusion coating, potentially leading to premature corrosion or leaking. The glass-lined panel, self-locking bolts, and sealant form the structure of glass fused to a steel tank, a highly durable tank.



Bolted Steel Tanks For PH Balancing Tanks Specifications



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,
salt fox, organic and inorganic compounds





Advantage of Bolted Steel Tanks For PH Balancing Tanks



Long service life with the lowest maintenance: Center Enamel's Glass-Fused-to-Steel Tank service life is more than 30 years, can be expanded or removed in the future if needed.



Various customized tank color options: we can mix any tank color according to customer's special requirement, which enables center Enamel's Glass-Fused-to-Steel Tank better integrate with the surrounding environment and buildings.



Cutting edge enameling technology guarantee premium product quality: specially developed enameling technology on sheets' four edges and bolt holes, which provide the best protection again harshest environment, less maintenance effort & cost after tank put into operation.



Wide structure configurations: CEC Glass-Fused-to-Steel tank is available in a wide range of sizes and capacities, from 18m3 to 25,000m3 to match your project needs.
