Place of Origin: | China |
Brand Name: | CEC TANKS |
Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
Model Number: | W20170706011 |
Minimum Order Quantity: | 1set |
Price: | $5000~$20000 one set |
Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
Delivery Time: | 10-30 days after deposit received |
Supply Ability: | 60 sets per month |
Detail Information |
|||
Place of Origin | China | Brand Name | CEC TANKS |
---|---|---|---|
Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W20170706011 |
Roof Available: | Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof | Chemical Resistance: | Excellent |
Size Of Panel: | 2.4M * 1.2M | Easy To Clean: | Smooth, Glossy, Inert, Anti-adhesion |
Corrosion Resistance: | Suitable For Waste Water Salt Water, Sea Water, High Sulfur Crude Oil, Salt Fox, Organic And Inorganic Compounds | Applications: | Water , Waste Water, Digester , Reactor , Grain , Sludge , Chemicals |
High Light: | OSHA Waste Water Storage Tanks,20000m3 Waste Water Storage Tanks,Anti Adhesion Waste Water Storage Tanks |
Center Enamel has a wide variety of water tanks, which are ideal for water treatment, septic tank systems and sewage treatment plants. Water is our most precious resource, and clean water is vital to communities, businesses, industries, and all aspects of life in our oceans and waterways. Water treatment filtration system is an integral part of society and industry. The water treatment system removes and removes pollutants in the water before re-entering the natural environment or using it.
There are many types of water treatment systems, from simple septic tank systems used in remote rural areas to more complex treatment systems used in small residential areas, to large-scale complete water treatment systems used in our towns. Water treatment systems are also widely used in industry, including manufacturing production, mining and resources, and environmental cleaning projects. Industrial uses of water treatment systems include the treatment of sewage and water used in operations. This includes treating or cleaning the water before recycling it.
For any application that must treat contaminated water, Zhengzhong Technology Water Treatment Tank is the ideal choice. If you want to reduce the cost of water treatment system, Zhengzhong Technology Water Treatment Tank is a good solution.
We have been producing storage tanks since 1989. Our products have been tested in this field for many years. Whenever you buy our storage tanks, you can rest assured. Zhengzhong Technology's wastewater treatment tanks are tailor-made and manufactured according to the specific requirements of customer facilities and wastewater treatment processes.
Glass fused to steel leachate storage tanks are mainly consisted of glass fused to steel plates, After firing at 820°C-930°C high temperature, the molten glass reacts with the steel plate surface to form an inert and inorganic bond, which combines the strength and flexibility of steel and outstanding corrosion resistance of glass, the glass fused to steel plates can resist PH range from 1 to 14. This feature allows glass fused to steel plates used for leachate storage tanks.
Glass Fused to Steel WaterTank Specifications
Coating color | dark blue, dark green, white, and customized |
A standard steel plate size | effective size 2400mm x 1200 m |
Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
Adhesion | 3,450N/cm |
Elastic | same as steel sheet, around 500KN/mm |
Hardness | 6.0 Mohs |
Service life | >30 years |
Spark test | >1500 V |
Permeability | gas and liquid impermeable |
Easy yo clean | smooth, glossy, inert, anti-adhesion |
Corrosion resistance |
excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds
|
Advantages of Glass Fused to Steel WaterTank
1. Short Construction Period: compare to over 90 days construction time of concrete tank, it takes even less than 15 days for installation of GFS Leachate Storage Tanks.
2. Superior Corrosion Resistance: Center Enamel Leachate Storage Tanks can resist PH range of 1 - 14.
3. Long Service Life: the Center Enamel GFS Tank are designed to work in a long service life as more than 30 years.
4. Tank Volume can be easily expand: GFS Leachate Storage Tanks are not only easy to construct, but also convenient to expand, remove and rebuild.
5. Beautiful Appearance: the color of glass fused to steel tank could be customized as per client’s request based on Pantone Matching System.
water and wastewater Storage Tanks Manufacturer and Supplier
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2020, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 90 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
