Payment & Shipping Terms:
|Material:||Glass Fused To Steel||Foundation:||Concrete Or Glass Fused Steel|
|Steel Grade:||ART 310||Roof:||Can Be Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof|
|Service Life:||Over 30 Years|
Glass Fused Water Storage Tanks,
ART 310 Water Storage Tanks,
ISO9001 Waste Water Storage Tanks
Glass Fused-To-Steel Water Storage Tanks For Fire Protection Water Storage
Glass-fused-to-steel (porcelain enamel) plate is integrated porcelain enamel and steel material fused together at 820°C-930°C, creating a hard inert, inorganic coating that never needs painting. Glass-fused-to-steel technology is the premium technology in the tank market.
Glass Fused-To-Steel Water Storage Tanks are considered to have advantages over other storage tank applications. Zhengzhong Technology can provide and install storage tanks for customers. For projects with storage requirements of more than 20 cubic meters, it is recommended to use this storage tank. These storage tanks can be used in industrial applications (including mines) and can be used to store materials such as waste water, sewage, sewage, drinking water, fire fighting water, and desalinated water.
Quality assurance and durability. This concept is reflected in the quality of the enamel assembly tank, which exceeds the requirements of international enamel standards. According to the structural requirements of AWWA D103-09 Structural Design Behavior Standard, the working life of Zhengzhong Technology's FRP bolt storage tank is 30 years.
Advantages of Glass Fused-To-Steel Water Storage Tanks
Lower cost of capital
Low maintenance cost
Fast installation time
Economic global shipments
Optimal corrosion resistance
The on-site installation of glass fused to steel storage tanks includes a unique jacking system. Once the starter plate (bottom ring) is embedded in the concrete foundation or designed and built with glass-coated bolted steel floor, the top ring of the tank is built on the jack. Then the top of the water tank was erected, and the lifting ring and the top were jacked up. For each additional ring, then assemble the bolt pieces below the top ring together, and apply a specially made polyurethane sealant between the seams.
All construction works are completed on the ground to ensure a safe, fast and efficient construction environment. The storage tank is usually completed within one to two weeks. If the general salary of on-site labor is used, it can save a lot of cost for the owner.
Glass Fused-To-Steel Water Storage Tanks Specifications
|Coating color||dark blue, dark green, white, and customized|
|A standard steel plate size||effective size 2400mm x 1200 m|
|Steel plates thickness||3mm - 12mm, depends on the diameter & height|
|Coating thickness||0.25mm - 0.4mm, two coatings internal and external|
|Acid and alkalinity proof||standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14|
|Elastic||same as steel sheet, around 500KN/mm|
|Service life||>30 years|
|Spark test||>1500 V|
|Permeability||gas and liquid impermeable|
|Easy yo clean||smooth, glossy, inert, anti-adhesion|
excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,
salt fox, organic and inorganic compounds
About Center Enamel Co., Ltd
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2020, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 90 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.
