Glass Fused To Steel 3mm Industrial Waste Water Storage Tanks
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W20160901010 |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
| Delivery Time: | 0-60 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W20160901010 |
| Tank Material: | Glass Fused To Steel | Steel Grade: | ART 310 |
| Steel Plates Thickness: | 3mm To 12mm , Depends On The Tank Structure | Roof Available: | Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof |
| Highlight: | ART 310 Waste Water Storage Tanks,3mm Thickness Waste Water Storage Tanks |
||
Product Description
Glass-Fused-to-Steel (Porcelain Enameled) Storage Tanks for Industrial Wastewater Treatment Projects
There are several advantages to using Glass-Fused-to-Steel (Porcelain Enameled) Storage Tanks to store potable water, corrosive and other liquid applications. In addition to being easy to assemble, they have greater life value, lower maintenance costs, and less environmental impact than other liquid storage structures. They have installed tens of thousands of municipal and industrial applications around the world over a period of more than decades, and they also have an extensive proven performance record.
Glass fused Steel (Glass Lined Steel) tank is a unique tank surface treatment. The two materials are fused together to achieve the best properties of both - the strength and flexibility of steel combined with the corrosion resistance of glass. Used on both internal and external surfaces, glass fused steel tanks provides years of trouble-free service in harsh environments. The system has been validated on thousands of installations for decades and is supported by international standards, including design and completion requirements:
Storage of drinking water, especially for municipal use.
Different stages of wastewater treatment (clarifying tank, sludge tank, storage tank and mixing tank).
Liquid food processing for the food processing industry.
Leachate storage. Leachate is a liquid that leaches into solid waste in landfills and in the process extracts soluble, dissolved and suspended material. Because landfills vary in composition and toxicity, and because they can seep into groundwater through the water table, the use of corrosion-free tanks is essential.
Industrial liquid storage is available for thousands of industrial liquid applications, such as food additives, paints and primers, fuel oils, pulp and paper.
Anaerobic digestion.
Liquid and bulk storage for agricultural purposes.
Glass-Fused-to-Steel (Porcelain Enameled) Storage Tanks Specifications
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
Glass Lined Steel Commercial Water Storage Tanks Manufacturer
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Glass Lined Steel Commercial Water Storage Tanks References
