Underground Wastewater Storage Tanks Ti - Rich Special Steel ART310 With AWWA D103-09 Standards
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden |
| Delivery Time: | 10-30 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W |
| Acid And Alkalinity Proof: | Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14 | Easy To Clean: | Smooth, Glossy, Inert, Anti-adhesion |
| Feature: | Eco-friendly, Durability | Usage: | Waste Water Treatment , Sewage Treatment, Effluent Treatment, Ect. |
| Steel Plates Thickness: | 3mm - 12mm , Depends On The Diameter & Height | Defect Free: | Minimum Maintenance Needed |
| High Light: | water treatment tank,sewage treatment tank |
||
Product Description
Ti-rich Special Steel ART310 Underground Wastewater Storage Tanks With AWWA D103-09 Standards
Glass fused to steel underground wastewater storage tank is a tank with excellent corrosion resistance, easy construction, service life is more than 30 years, which is different from the traditional tanks like a concrete tank. For a concrete tanks, the construction time is very long and the maintenance cost is very high, once install the volume can’t be changed. All our underground wastewater storage tanks engineering design meet or exceed AWWA D103-09 and EN/ISO28765:2011, and our underground wastewater storage tank engineers make tank engineering calculation on each specific underground wastewater storage tank structure according to project local environmental conditions, such as snow load, wind speed, seismic zone etc., to make sure the tank structure's adequate security in long-term service life.
We produce the glass fused to steel tank with the ART 310 enamel special steel sheet, and it’s surface fused with enamel frit. Enamel frit is the material similar with the glass, so the acid and alkali proof is very good. Fused these two materials into the high temperature in the high temperature, the result is made these two materials into a single composite material.
Ti-rich Special Steel ART310 Advantage:
To improve the steel quality performance after enameling, we developed special steel ART310 with Angang Steel Group in 2005.
1. Increase the adhesive power between steel and enamel coating.
2. Significantly solve fish scaling problem.
3. Improve the steel yield strength after firing.
Underground Wastewater Storage Tanks Specifications
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
