Gas / liquid impermeable Waste Water Storage Tank With Short Construction Period

Waste Water Storage Tank With Short Construction Period And Not Subject To Weather Condition

What is glass fused to steel tank ?

Glass fused to steel tank is fused with both Ti-rich steel sheet and enamel frits in 800-900 degree high temperature stove to make it become into one material. The service life is more than 30 years and acid and alkali proof are excellent. GFS tank is not only with the strength and flexibility of steel ,but also with the excellent corrosion resistance of glass.

Glass fused to steel tank is the prefabricated tank, so there is no need any big equipment during the installation. The installation time of GFS tank is short and the maintenance cost is little. The steel round (cylindrical) shell of the tank is built from two-layer enameled sheets(according to the different application thickness of coating can be designed accordingly) coated on both sides. The sheets are attached with special high-grade bolts and sealed by constantly flexible polyurethane or silicone sealant. The surface of connecting material and the shell itself are properly treated.

GFS technology is able to withstand the rigorous of the construction site and provide many years of trouble free service in harsh environments.

Advantages of our GFS tanks

Oversea projects reference

-- 2008 Beijing Olympics Games wastewater project

-- 2009 Niger Azelik uranium deposits(China National Nuclear Corporation)

-- 2009 Niger Azelik uranium deposits(China National Nuclear Corporation)

-- 2009-2013 Palm oil wastewater treatment project in Indonesia

-- 2011 Anyang city Biogas project

-- Chengde Biology waste water project

-- Brewery wastewater treatment

-- Shandong Garbage waste water treatment project

-- Pharmacy waste water treatment project

-- 2013 Sichuan Chengdu Pharmaceutical waste water treatment

-- 2014 Urban sludge treatment project- Kazakhstan

-- 2016 Ecuador potable water storage project

Specification of GFS tank

1. Coating color : standard dark green and dark blue, color can be customized

2. Coating thickness : 0.25mm - 0.4mm, two coating internal and external

3. Acid and alkalinity proof : standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14

4. Adhesion : 3,450N/cm

5. Elastic : same as steel sheet , around 500KN/mm

6. Hardness : 6.0 Mohs

7. Service life : >30 years

8. Spark test : >1500 V

9. Permeability: gas and liquid impermeable

10. Easy to clean : smooth, glossy, inert, anti-adhesion

11. Corrosion resistance : excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds
