Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof ART 310 Steel grade

Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof ART 310 Steel grade
Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof ART 310 Steel grade Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof ART 310 Steel grade

Large Image :  Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof ART 310 Steel grade

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20161020002
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Design Life: 50years Tank Body Color: Dark Green / Can Be Customized
Foundation: Concrete Or Glass Fused Steel Steel Grade: ART 310
High Light:

porcelain enamel glass lined tank

,

gls tank

Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof





What is Glass Lined Steel(GLS) Tanks?



As the most popular solution for Water Storage, Glass Lined Steel(GLS) Tanks are widely used for potable water storage, fire-fighting water storage,irrigation water storage etc. GLS tanks strictly comply with AWWA D103,OSHA and EN28765 standard.



Due to the excellent quality and most competitive price, GLS tanks have been exported to USA, Australia, Singapore, Malaysia, Russia , New Zealand and other more than 25 countries.



Advantage of Aluminum Deck Roof



• Most economic roof

• Easy installation

• Light weight

• High strength

• Durable

• Nice appearance

• Anti oxidation

• Store least amount of heat and get cool very quickly



Fundamental Characteristics



Category Specification
Coating Color dark green, white, blue and also color can be customized
Coating Thickness 0.25 - 0.40mm , double coating
Acid and alkalinity proof Standard pH: 3 - 11
Special pH: 1 - 14
Adhesion 3450 N / cm
Elastic Same as steel sheet, around 500 kN / mm
Hardness 6.0 ( Mohs )
Service life ≥ 30 Years
Holiday test > 1500 V
Permeability Gas / liquid impermeable
Easy to clean Smooth, glossy, inert, anti-adhesion
Corrosion resistance Excellent,suitable for water storage, waste water treatment, sewage treatment, high suifur crude oil,salt fox,organic and inorganic compounds



Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof ART 310 Steel grade 0



Advantage of Glass Lined Steel Tanks



1. Short installation period : compare to more than 40days installation time for other type tanks, usually GLS tanks only needs even less than 15days.

2. Superior corrosion resistance : GLS tanks can resist pH rage 1-14.

3. Beautiful appearance : Standard color is dark green, and color can be customized according to customer’s request.

4. Climate adaptability : GLS tanks can be used in almost all kinds of weather conditions, that is very important for some special areas.

5. Long service life : more than 30 years service life.

6. Easy construction : No requirement for big installation equipment, and can be easily expand, dismantle and move.



Over 2000m3 Glass Lined Water Storage Tanks with Aluminum Deck Roof ART 310 Steel grade 1
