Gas / Liquid Impermeable Above Ground Fuel Storage Tanks 3450 N / Cm Adhesion

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20160504019
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Product Description

Most Economical Glass-Fused-to-Steel Tank: Expandable and Reliable



Shijiazhuang Zhengzhong Technology Co., Ltd has been a leader in the bolted storage tank industry since 1989, specializing in the design and fabrication of high-quality Glass-Fused-to-Steel (GFS) tanks. Our GFS tanks are known for their cost-effectiveness, expandability, and reliability, making them the most economical choice for various storage needs.





As a leading storage tank manufacturer in China. Center Enamel can provide Glass-Fused-to-Steel (GFS) tanks, fusion bonded epoxy tanks, stainless steel tanks, galvanized steel tanks and aluminum geodesic dome roofs, Wastewater and Biogas Project Equipments for global customers.



Configuration of Customized Storage Tanks
Storage tanks Volume Roofs Application Design Requirements

GFS Tanks

SS Tanks

Fusion Bonded Epoxy Tanks

Galvanized Steel Tanks

<1000m³

1000-10000m³

10000-20000m³

20000-25000m³

>25000m³

ADR Roof

GFS Roof

Membrane Roof

FRP Roof

Trough Deck Roof

Wastewater Treatment Project

Drinking Water Project

Municipal Sewage Project

Biogas Project

Fire Water Storage Project

Oil Storage Project

Water Supply & Drainage System

Seismic Design

Wind Resistant Design

Lightning Protection Design

Tank Insulation Design



WasteWater Treatment Project Equipment Supply

Pretreatment Equipment Resource Utilization System Sludge Treatment System Other Equipment

Mechanical Bar Screen

Solid-liquid Separator

Submersible Mixer

Gas Holder

Boiler System

Boost Fan

Biogas Generator

Torch System

Dehydration and Desulfurization Tank

PAM Integration Dosing Device

Screw Sludge Dewatering Machine

Slurry Separation Centrifuge

Sewage Pump

Mud Scraper

Submersible Sewage Pump

Three-phases Separator







The Advantages of Glass-Fused-to-Steel Tanks

Cost-Effective Solution:

Our GFS tanks offer a highly economical solution compared to traditional concrete, welded steel, or epoxy-coated tanks. The combination of glass and steel ensures long-term durability with minimal maintenance costs.



Expandable Design:

The modular nature of our Glass-Fused-to-Steel tanks allows for easy expansion. This feature is particularly beneficial for projects that may require increased storage capacity in the future, providing flexibility and cost savings.



Durability and Longevity:

The glass coating on our steel tanks provides superior resistance to corrosion, harsh chemicals, and extreme weather conditions. Our tanks are designed to last over 35 years, ensuring a long-term, reliable storage solution.



Customizable Options:

We offer a range of customizable options for our tanks, including various sizes, capacities, colors, and heights. This ensures that our tanks meet the specific needs of different projects and applications.



Compliance with International Standards:

Our GFS tanks comply with international standards such as ISO 9001, NSF/ANSI 61, WRAS, and ISO 28765. This guarantees the highest quality and safety for our products.



Key Features

Superior Corrosion Resistance:

The glass coating provides excellent protection against corrosion, making our tanks ideal for storing a variety of substances, including potable water, industrial effluents, and municipal sewage.



Chemical Resistance:

Our tanks can withstand pH levels ranging from 3 to 11, ensuring their suitability for various industrial applications.



High Strength and Durability:

The fusion of glass and steel results in a robust structure capable of withstanding environmental and operational stresses.



Low Maintenance:

The smooth, glossy surface of the glass coating is easy to clean and prevents the buildup of contaminants, reducing maintenance efforts and costs.



Applications

Our Glass-Fused-to-Steel tanks are versatile and can be used in a wide range of applications, including:



Potable Water Storage:

Ensuring safe and clean drinking water with tanks that meet NSF/ANSI 61 standards.



Industrial Effluents:

Providing reliable storage for various industrial waste products.



Municipal Sewage:

Offering durable and corrosion-resistant tanks for sewage treatment plants.



Bio-Energy Projects:

Supporting sustainable energy solutions with high-quality storage tanks.



Agriculture:

Storing water and other agricultural liquids efficiently and safely.



Technical Specifications

Coating Color: Dark blue, dark green, white, and customizable options

Standard Steel Plate Size: Effective size 2400mm x 1200mm

Steel Plate Thickness: 3mm - 12mm, depending on diameter and height

Coating Thickness: 0.25mm - 0.4mm, with internal and external coatings

Acid and Alkalinity Resistance: Standard coating suits for pH 3 - pH 11, special coating suits for pH 1 - pH 14

Adhesion: 3,450N/cm

Elasticity: Similar to steel sheet, around 500KN/mm

Hardness: 6.0 Mohs

Service Life: Over 35 years

Spark Test: >1500 V

Permeability: Gas and liquid impermeable

Ease of Cleaning: Smooth, glossy, inert, anti-adhesion surface

Corrosion Resistance: Excellent, suitable for wastewater, saltwater, seawater, high sulfur crude oil, salt fog, organic and inorganic compounds

Why Choose Shijiazhuang Zhengzhong Technology Co., Ltd?

Industry Leader:

With over three decades of experience, we are the most experienced professional bolted tanks manufacturer in Asia.



Innovative R&D:

Our dedicated R&D team continuously develops new technologies and improvements, holding over 20 enameling patents.



Global Reach:

Our tanks are used in over 100 countries, including the USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, Brazil, and South Africa. We are recognized worldwide for our superior tank quality and prompt service.



Choosing Glass-Fused-to-Steel tanks from Shijiazhuang Zhengzhong Technology Co., Ltd means investing in an economical, expandable, and reliable storage solution. Our commitment to quality, innovation, and customer satisfaction ensures that you receive a product that performs reliably and efficiently for decades.Center Enamel combines the excellent performance of various tanks to provide customers with solutions composed of diverse equipment combinations. This approach allows us to flexibly meet the needs and requirements of different application fields. Throughout the project construction process, the teams at Center Enamel collaborate closely, actively coordinate, and prioritize each step, conducting rigorous checks at every level to ensure the smooth completion of projects.



From being a leader in the Asian GFS tank industry to becoming a diversified environmental equipment smart manufacturer in China, Center Enamel utilizes crucial core technologies to continuously iterate and upgrade equipment in research and development. This drives the sustained high-quality development of the company in the face of new challenges. Leveraging existing brand advantages, technological strengths, and team capabilities, the company will continue to focus on cutting-edge industry technologies. Adhering to a diversified development strategy, Center Enamel aims to elevate environmental business to new heights while jointly creating a beautiful picture of green hills and clear waters.
