Place of Origin: | China |
Brand Name: | CEC TANKS |
Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
Model Number: | W20160504017 |
Minimum Order Quantity: | 1set |
Price: | $5000~$20000 one set |
Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
Delivery Time: | 0-60 days after deposit received |
Payment Terms: | L/C, T/T |
Supply Ability: | 60 sets per month |
Detail Information |
|||
Glass-Fused-to-Steel Tanks with Superior Chemical Resistance (pH 3-11)
Shijiazhuang Zhengzhong Technology Co., Ltd has been at the forefront of the bolted storage tank industry since 1989, specializing in the design and fabrication of high-quality Glass-Fused-to-Steel (GFS) tanks. Our tanks are renowned for their superior chemical resistance, capable of withstanding harsh environments with pH levels ranging from 3 to 11.
Unmatched Durability and Chemical Resistance
Our Glass-Fused-to-Steel tanks are engineered by fusing a layer of glass to steel at high temperatures, creating an extremely durable and chemically resistant surface. This unique combination of glass and steel offers numerous advantages over traditional epoxy-coated or welded steel tanks, making our GFS tanks the ideal choice for a wide range of applications.
As a leading storage tank manufacturer in China. Center Enamel can provide Glass-Fused-to-Steel (GFS) tanks, fusion bonded epoxy tanks, stainless steel tanks, galvanized steel tanks and aluminum geodesic dome roofs, Wastewater and Biogas Project Equipments for global customers.
Configuration of Customized Storage Tanks | ||||
Storage tanks | Volume | Roofs | Application | Design Requirements |
GFS Tanks SS Tanks Fusion Bonded Epoxy Tanks Galvanized Steel Tanks |
<1000m³ 1000-10000m³ 10000-20000m³ 20000-25000m³ >25000m³ |
ADR Roof GFS Roof Membrane Roof FRP Roof Trough Deck Roof |
Wastewater Treatment Project Drinking Water Project Municipal Sewage Project Biogas Project Fire Water Storage Project Oil Storage Project |
Water Supply & Drainage System Seismic Design Wind Resistant Design Lightning Protection Design Tank Insulation Design |
WasteWater Treatment Project Equipment Supply
Pretreatment Equipment | Resource Utilization System | Sludge Treatment System | Other Equipment |
Mechanical Bar Screen Solid-liquid Separator Submersible Mixer |
Gas Holder Boiler System Boost Fan Biogas Generator Torch System Dehydration and Desulfurization Tank |
PAM Integration Dosing Device Screw Sludge Dewatering Machine Slurry Separation Centrifuge |
Sewage Pump Mud Scraper Submersible Sewage Pump Three-phases Separator |
Key Features and Benefits
Superior Chemical Resistance:
The glass coating on our tanks provides exceptional resistance to both acidic and alkaline environments, with a pH range of 3 to 11. This ensures the integrity and longevity of the tanks in various industrial and municipal applications.
Extended Lifespan:
Our Glass-Fused-to-Steel tanks are designed to last over 35 years, significantly reducing maintenance and replacement costs. The glass coating protects the steel from corrosion, ensuring the tanks remain structurally sound for decades.
Customizable Solutions:
We offer customizable tank solutions to meet specific project requirements. Our tanks come in various sizes and capacities, with customizable colors and heights to ensure they perfectly fit your needs.
Compliance with International Standards:
Our tanks adhere to strict international standards, including ISO 9001, NSF/ANSI 61, WRAS, ISO 28765, and more. This guarantees that our products meet the highest quality and safety benchmarks.
Versatile Applications:
Our Glass-Fused-to-Steel tanks are suitable for a wide range of applications, including drinking water storage, industrial effluents, municipal sewage, bio-energy projects, landfill leachate, and agriculture.
Why Choose Shijiazhuang Zhengzhong Technology Co., Ltd?
Experience and Expertise:
With over three decades of experience, we are the most experienced professional bolted tanks manufacturer in Asia. Our expertise in enameling technology and tank fabrication ensures the highest quality products.
Innovative R&D:
Our dedicated R&D team continuously works on improving our products and technologies. We hold more than 20 enameling patents, reflecting our commitment to innovation and excellence.
Global Reach:
Our tanks have been exported to over 100 countries, including the USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, Brazil, and South Africa. Our superior tank quality and prompt service have earned us worldwide recognition.
Technical Specifications
Coating Color: Dark blue, dark green, white, and customizable options
Standard Steel Plate Size: Effective size 2400mm x 1200mm
Steel Plate Thickness: 3mm - 12mm, depending on diameter and height
Coating Thickness: 0.25mm - 0.4mm, two coatings internal and external
Acid and Alkalinity Resistance: Standard coating suits for pH 3 - pH 11, special coating suits for pH 1 - pH 14
Adhesion: 3,450N/cm
Elasticity: Same as steel sheet, around 500KN/mm
Hardness: 6.0 Mohs
Service Life: Over 35 years
Spark Test: >1500 V
Permeability: Gas and liquid impermeable
Ease of Cleaning: Smooth, glossy, inert, anti-adhesion surface
Corrosion Resistance: Excellent, suitable for wastewater, saltwater, seawater, high sulfur crude oil, salt fog, organic and inorganic compounds
Choosing Glass-Fused-to-Steel tanks from Shijiazhuang Zhengzhong Technology Co., Ltd means investing in a product that offers superior chemical resistance, long-term durability, and customizable solutions to meet your specific needs. Our commitment to quality, innovation, and customer satisfaction ensures that you receive a tank that performs reliably and efficiently for decades.
Center Enamel combines the excellent performance of various tanks to provide customers with solutions composed of diverse equipment combinations. This approach allows us to flexibly meet the needs and requirements of different application fields. Throughout the project construction process, the teams at Center Enamel collaborate closely, actively coordinate, and prioritize each step, conducting rigorous checks at every level to ensure the smooth completion of projects.
From being a leader in the Asian GFS tank industry to becoming a diversified environmental equipment smart manufacturer in China, Center Enamel utilizes crucial core technologies to continuously iterate and upgrade equipment in research and development. This drives the sustained high-quality development of the company in the face of new challenges. Leveraging existing brand advantages, technological strengths, and team capabilities, the company will continue to focus on cutting-edge industry technologies. Adhering to a diversified development strategy, Center Enamel aims to elevate environmental business to new heights while jointly creating a beautiful picture of green hills and clear waters.
