18000m3 Anaerobic Digestion Tanks Glass Fused Steel Foundation

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20171016010
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 10-30 days after deposit received
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W20171016010
Design Life: 50years Capacity: 20 M3 To 18,000 M3
Tank Body Color: Dark Green / Can Be Customized Foundation: Concrete Or Glass Fused Steel
Size Of Panel: 2.4M * 1.2M Usage: Waste Water Treatment , Sewage Treatment, Effluent Treatment, Ect
High Light:

18000m3 Anaerobic Digestion Tanks


Glass Fused Steel Anaerobic Digestion Tanks

Product Description

Harnessing the Green Power of Anaerobic Digestion Tanks


Anaerobic digestion tanks, often referred to as anaerobic digesters, are sophisticated bioreactors that play a pivotal role in sustainable waste management and renewable energy production. These tanks employ the power of microorganisms to break down organic matter in the absence of oxygen, transforming waste materials into valuable biogas and nutrient-rich byproducts. In this article, we'll delve into the fascinating world of anaerobic digestion tanks, exploring their inner workings, applications, and the significant environmental benefits they offer.

Anaerobic digestion is a sustainable and environmentally friendly technology that has the potential to address both waste management and renewable energy needs. The success of this process heavily depends on the reliability of anaerobic digestion tanks, and Glass-Fused-to-Steel (GFS) tanks have risen to the challenge. With their exceptional corrosion resistance, durability, chemical resistance, ease of maintenance, cost-effectiveness, and environmental benefits, GFS tanks are at the forefront of transforming anaerobic digestion into a viable solution for organic waste management and clean energy generation. As the world seeks sustainable alternatives, GFS tanks are making a significant impact in promoting a greener and more efficient future.


The Anaerobic Digestion Process


Anaerobic digestion is a natural process that occurs in the absence of oxygen. It involves a complex series of biological reactions driven by a consortium of microorganisms, primarily bacteria and archaea. These microorganisms work together to break down organic matter, such as agricultural waste, sewage sludge, food scraps, and more, into biogas and digestate.


Initial Stages: The anaerobic digestion process begins with the hydrolysis stage, where enzymes break down complex organic molecules into simpler compounds. These compounds are then converted into volatile fatty acids through acidogenesis.


Acetogenesis: During this phase, acetogenic bacteria further metabolize the volatile fatty acids into acetic acid, hydrogen, and carbon dioxide.


Methanogenesis: In the final stage, methanogenic archaea take over. They utilize the products of previous stages—acetic acid, hydrogen, and carbon dioxide—to produce methane (CH4), the primary component of biogas.


Anaerobic Digestion Tank Components


Anaerobic digestion tanks are designed to facilitate and control these microbial processes. They typically consist of the following components:


Inlet System: Organic waste materials, in liquid or slurry form, are introduced into the tank through an inlet system.


Bioreactor: The heart of the anaerobic digestion tank, this is where microorganisms carry out the digestion process. The tank is equipped with temperature and pH control systems to optimize microbial activity.


Gas Collection System: As biogas is produced, it is collected and stored. Biogas primarily consists of methane (50-75%) and carbon dioxide (25-50%), with trace amounts of other gases.


Digestate Storage: The solid and liquid remnants of the digestion process, known as digestate, are stored in separate compartments. This nutrient-rich material can be used as a valuable fertilizer.


Applications of Anaerobic Digestion Tanks


Anaerobic digestion tanks have a wide range of applications, making them a versatile tool for sustainable resource management:


Waste Management: Anaerobic digestion is highly effective at treating organic waste, reducing its volume, and mitigating odors. This is particularly useful for treating sewage sludge, agricultural residues, and food waste.


Biogas Production: The biogas produced in anaerobic digestion tanks can be harnessed as a renewable energy source. It can be used for electricity generation, heating, or as a vehicle fuel, reducing greenhouse gas emissions.


Wastewater Treatment: Anaerobic digestion can be integrated into wastewater treatment plants to enhance the removal of organic pollutants while simultaneously producing biogas.


Agricultural Benefits: The digestate produced in anaerobic digestion tanks is a nutrient-rich fertilizer that can improve soil quality and crop yields.

As a leading storage tank manufacturer in China. Center Enamel can provide GFS Tanks, SS Tanks, Epoxy Coated Bolted Steel Tanks, Galvanized Tank, Aluminum Dome Roofs, Wastewater and Biogas Project Equipments for global customers.


Configuration of Customized Storage Tanks
Storage tanks Volume Roofs Application Design Requirements

GFS Tanks

SS Tanks

Fusion Bonded Epoxy Tanks

Galvanized Steel Tanks






ADR Roof

GFS Roof

Membrane Roof

FRP Roof

Trough Deck Roof

Wastewater Treatment Project

Drinking Water Project

Municipal Sewage Project

Biogas Project

Fire Water Storage Project

Oil Storage Project

Water Supply & Drainage System

Seismic Design

Wind Resistant Design

Lightning Protection Design

Tank Insulation Design


WasteWater Treatment Project Equipment Supply

Pretreatment Equipment Resource Utilization System Sludge Treatment System Other Equipment

Mechanical Bar Screen

Solid-liquid Separator

Submersible Mixer

Gas Holder

Boiler System

Boost Fan

Biogas Generator

Torch System

Dehydration and Desulfurization Tank

PAM Integration Dosing Device

Screw Sludge Dewatering Machine

Slurry Separation Centrifuge

Sewage Pump

Mud Scraper

Submersible Sewage Pump

Three-phases Separator




Shijiazhuang Zhengzhong Technology Co.,Ltd is a professional manufacturer dedicated to the design and fabrication of bolted storage tanks since 1989. Our products range includes Glass-Fused-to-Steel (GFS) tanks, fusion bonded epoxy tanks, stainless steel tanks, galvanized steel tanks and aluminum geodesic dome roofs. With professional enameling R&D team and more than 20 enameling patents, Shijiazhuang Zhengzhong Technology Co.,Ltd has become the leader in bolted tanks industry of Asia. Our products are certified to ISO 9001, NSF/ANSI 61, WRAS, ISO 28765, LFGB, BSCI, ISO 45001 and other international standards.


Shijiazhuang Zhengzhong Technology Co., Ltd is not only the first manufacturer in China which produces Glass-Fused-to-Steel tanks, but also the most experienced professional bolted tanks manufacturer in Asia. The engineering & design, product testing and quality system of Center Enamel Glass-Fused-to-Steel tanks is in strict accordance with AWWA D103-09, OSHA, ISO 28765, NSF/ANSI 61, NFPA and other international standards. Center Enamel Glass-Fused-to-Steel tanks are wildly used in drinking / potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture and other applications. Until 2022, Center Enamel bolted tanks have been exported to more than 90 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, Brazil and South Africa etc., the superior tank quality and prompt service gains us worldwide recognition.


As an outstanding containment and cover system provider with more than 30 years of experience, Shijiazhuang Zhengzhong Technology Co., Ltd sincerely expects to establish long-term cooperation with the local partners throughout the world and make continuous contribution to the development of the industry.
