AWWA D103 Glass Fused Steel Tanks Poultry And Livestock Manure Storage

AWWA D103 Glass Fused Steel Tanks Poultry And Livestock Manure Storage
AWWA D103 Glass Fused Steel Tanks Poultry And Livestock Manure Storage

Large Image :  AWWA D103 Glass Fused Steel Tanks Poultry And Livestock Manure Storage

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: J2016012654
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Adhesion: 3,450N/cm Elastic: Same As Steel Sheet ,around 500KN /mm
Acid And Alkalinity Proof: Standard Sheet PH:3~11 Special Sheet PH: 1~14 Service Life: ≥30 Years
Permeability: Gas And Liquid Impermeable Material: Glass And Steel
Coating Color: Can Be Customized Coating Thickness: 0.25mm~0.40mm & Double Coating
High Light:

AWWA D103 Glass Fused Steel Tanks

,

Poultry Storage Glass Fused Steel Tanks

Poultry And Livestock Manure Storage Tanks

Poultry and livestock manure storage is an indispensable part of modern farms. The farm must be equipped with enough manure storage tanks to collect a large amount of manure flushing water and polluted runoff in today's farms and reduce the impact of farming sewage on the environment. Nowadays many farms used Glass-Lined steel tanks to store poultry and livestock manure.



What are Glass-Lined Steel Tanks

After firing at a high temperature of 820°C-930°C, the molten glass reacts with the surface of the steel plate to form an inert and inorganic bond, which combines the strength and flexibility of steel and excellent glass corrosion resistance. Therefore, glass-lined steel storage tanks provide many advantages over standard epoxy storage tanks or welded and painted storage tanks. Glass-lined steel technology is a high-quality coating technology in the storage tank market. Glass-lined steel tanks are widely used in applications such as bio-energy, municipal sewage, landfill leachate, and industrial wastewater treatment.

Our Water Storage tanks



Storage tanks Volume Roofs Accessories Application
GFS Tanks
SS Tanks
Steel Tanks
20-20000m³ ADR Roof
GFS Roof
Membrane Roof
FRP Roof
Trough Deck Roof
Ladders
Platforms
Pumps
Three-phase Separator
Biogas Purification System
Wastewater Treatment Project
Drinking Water Project
Municipal Sewage Project
Biogas Project
Fire Water Storage Project
Oil Storage Project





Compared with other types of storage tanks, glass-lined steel tanks have significant advantages for customers, consultants, and contractors. The internal and external surfaces of the glass-lined steel tank are treated by melting glass to steel to provide long-term protection and have the following advantages:

Long life, reducing operating costs

Modular bolt tank structure, fast and cost-effective on-site installation-reduce project time, cost, and requirements for on-site equipment

Flexible shape, small footprint

Storage tanks can be expanded, disassembled and relocated, providing long-term asset value

The optimal corrosion resistance of glass fused steel

Safe and reliable storage, lowest maintenance cost

Complete range of diameter and height options, storage capacity solutions over 25,000m³, the most cost-effective solution

The installation time of the glass-lined steel tank depends on the size of the installed tank and the complexity of the installation process. Generally, the installation speed is very fast, usually less than one-third of the time required to complete a welded tank or concrete tank, but factors such as site complexity or specific job requirements can change the installation time.

The glass-lined steel tank is manufactured and produced in the factory and then transported to the project site for assembly. Each part is erected, sealed with gaskets, and bolted to adjacent parts. This results in a quick and easy installation process, much faster than the installation of concrete or welded storage tanks, and is not affected by weather delays, greatly reducing the time and labor on site.

How are they assembled?

Starting from the bottom of the structure, each panel is erected one layer at a time. Gaskets are installed between adjacent panel parts to form a firm seal and prevent damage to adjacent metal surfaces. Then install the appropriate fasteners and tighten them to specifications. Add accessories such as valves, doors, or manhole covers if necessary, and finally install the top cover of the tank. Since the installation is carried out in a larger part, the storage tank can be erected quickly, without sandblasting, painting, or other preparations on site.


AWWA D103 Glass Fused Steel Tanks Poultry And Livestock Manure Storage 0
