Place of Origin: | China |
Brand Name: | CEC TANKS |
Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
Model Number: | J2016012306 |
Minimum Order Quantity: | 1set |
Price: | $5000~$20000 one set |
Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
Delivery Time: | 0-60 days after deposit received |
Payment Terms: | L/C, T/T |
Supply Ability: | 60 sets per month |
Detail Information |
|||
Place of Origin | China | Brand Name | CEC TANKS |
---|---|---|---|
Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | J2016012306 |
Acid And Alkalinity Proof: | Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14 | Usage: | Waste Water Treatment , Sewage Treatment, Effluent Treatment, Ect. |
Corrosion Resistance: | Excellent ! Suitable For Waste Water Salt Water, Sea Water, High Sulfur Crude Oil, Salt Fox, Organic And Inorganic Compounds | Spark Test: | >1500 V |
Service Life: | Over 30 Years | Capactiy Available: | 20 M3 To 18,000 M3 |
PH Range: | A Grade Sheet PH:3-11, AA Grade Sheet PH : 1-14 | Highlight: | 18000m3 Drinking Water Storage Tanks,BSCI Drinking Water Storage Tanks,20m3 Drinking Water Storage Tanks |
Our drinking water tanks are available in different sizes, ranging from 20m³ to 25,000 m³. These Glass-Fused-to-steel water tanks are made of food-grade enameled steel plates to ensure durability, with a smooth interior that prevents the growth of bacteria and is easy to clean.
These popular storage tanks can be interconnected to a capacity of 25000m³ using flange connections. These enamel assembled tanks can be installed faster than traditional steel water storage tanks and can be used in commercial liquid supply systems, water supply systems, construction water and water treatment systems.
Center Enamel Co., Ltd is not only the first Enamel steel Potable Water And Drinking Water Storage Tanks manufacturer and supplier in China, but also the most experienced glass lined steel tanks manufacturer in all of Asia. Center Enamel porcelain enamel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass Lined Steel Potable Water And Drinking Water Storage Tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel porcelain enamel tanks have been exported to more than 80 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Potable Water And Drinking Water Storage Tanks Specifications
Coating color | dark blue, dark green, white, and customized |
A standard steel plate size | effective size 2400mm x 1200 m |
Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
Adhesion | 3,450N/cm |
Elastic | same as steel sheet, around 500KN/mm |
Hardness | 6.0 Mohs |
Service life | >30 years |
Spark test | >1500 V |
Permeability | gas and liquid impermeable |
Easy yo clean | smooth, glossy, inert, anti-adhesion |
Corrosion resistance | excellent! Suitable for wastewater saltwater, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
