20m3 Bolted Steel Liquid Storage Tanks For Fire Protection Water Storage
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden |
| Delivery Time: | 10-30 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W |
| Coating Thickness: | 0.25mm~0.40mm , Two Layer Of Coating Internal And External | Steel Grade: | ART 310 |
| Size Of Panel: | 2.4M * 1.2M | Capactiy Available: | 20 M3 To 20,000 M3 |
| Easy To Clean: | Smooth, Glossy, Inert, Anti-adhesion | Easy To Cle: | Smooth, Glossy, Inert, Anti-adhesion |
| Warranty Period: | 2 Years Free Of Charge | FeatureEco-friendly: | Durability |
| Capactiy Availabl: | E20 M3 To 20,000 M3 | Impact: | ResistanceExcellent |
| Installation: | By Jacking Machine Or Steel Pole, Fast In Installation | High Light: | 20m3 Liquid Storage Tanks,Smooth PH14 Liquid Storage Tanks |
Product Description
Bolted Steel Liquid Storage Tanks For Fire Protection Water Storage
In the field of fire protection water storage tanks, there are several types of storage tank options, and some of the most commonly used are corrugated steel tanks, welded steel tanks, bolted steel tanks, and concrete tanks. We have found that for most projects, the bolted steel design has the most advantages over other types when considering cost, manufacturing quality, field erection time, and product durability.
Our bolted steel tanks are made from high-quality Glass-Fused-to-Steel panels. All the Glass-Fused-to-Steel panels and tanks accessories are manufactured in a factory and are bolted together at the desired location. Our glass-lined steel tank is the perfect choice for fire protection water storage.
Standard sizes for glass fused to steel tanks go up to almost 20000m³; however, custom sizes and dimensions are also available. Center Enamel also offers multiple roof options: Glass-Fused-to-Steel roof with external/internal beams, Aluminum Alloy Trough Deck Roofs, FRP Roofs, Aluminum Dome Roofs. Bolted steel tanks can be disassembled and moved as needed and installed quickly by a small team.
bolted steel tanks Specifications
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater saltwater, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
The bolted storage tank is the best choice for 200000 Gallon fire protection water storage. Over 30 years of bolted steel tanks manufacture experience, Center Enamel has become the bolted steel tanks industry leader in Asia and is certified to ISO9001, NSF61LFGB, BSCI and other international standards. And our bolted steel tank engineers make tank engineering calculations on each specific tank structure according to project local environmental conditions, such as snow load, wind speed, seismic zone etc., to make sure the tank structure's adequate security in long-term service life. Also, our bolted steel tanks have been exported to more than 80 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
