Commercial Fire Fighting Water Tanks with Glass fused steel roof

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W
Tank Material: Glass Fused To Steel Foundation: Concrete Or Glass Fused Steel
Steel Grade: ART 310 Roof Available: Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof
Corrosion Integrity: Excellent Chemical Resistance: Excellent
Elastic: Same As Steel Sheet ,around 500KN /mm High Light:

500KN/mm Fire Fighting Water Tanks

,

Glass fused Fire Fighting Water Tanks

Product Description

Zhengzhong Technology provides customers with professional fire-fighting water tanks to adapt to commercial applications



Zhengzhong Technology provides customers with professional fire-fighting water tanks to adapt to commercial applications that comply with international storage tank standards. Our fire-fighting water tanks are equipped with all the fire-fighting water tank signs, liquid level indicators, anti-turbulence outlets and other related nozzles that meet the requirements.



For rural properties, we can provide fire-fighting water tanks of appropriate size as a dedicated static water source to protect assets, or provide fire-fighting water tanks with bushfires for new houses.



Genzon Technology provides a series of steel fire-fighting water storage tanks suitable for automatic sprinkler systems and fire hydrant systems. Since 1989, we have been producing these fire boxes for more than 30 years.

All of our fire water tanks are produced in production plants in China, which allows us to control the quality and provide a shorter delivery time on all products, which is the leading advantage of fire water tank design.



Center Enamel Co., ltd is a manufacturer dedicated in glass fused steel bolted fire water storage tanks for more than 30 years , our Glass-Fused-to-steel bolted tanks are widely applied in bio-energy, waste water treatment, potable water storage and dry bulk storage etc. fire water storage tank is ideally suited to providing protection for homes and barns.





fire water storage tank Specifications



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,

salt fox, organic and inorganic compounds





Comparison between GFS Tanks and Concrete Tanks



1. Easy Construction: All the tank shells of Glass-Fused-To-Steel Tanks are factory coated, can be easily assembled and installed in difficult conditions, to meet the urgency requirement of project, unlike Concrete Tanks will be affected seriously by bad weather and other factors.



2. Corrosion Resistance: Concrete tank would corroded through to reinforcing bar within 5 years of installation, Glass-Fused-To-Steel Tanks with 2 layer of Glass coating, can be applied for PH from 3 to 11, Center Enamel also provide 2 Years Warranty of its Glass-Fused-To-Steel Tanks.



3. Leakage and Maintenance: Concrete is susceptible to cracking so that many Concrete Tanks show signs of visible leaks and require substantial remedial maintenance, Glass-Fused-To-Steel Tanks are an excellent alternative with less maintenance due to the steel strong tension strength.

About Center Enamel Co., Ltd



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
