Place of Origin: | China |
Brand Name: | CEC TANKS |
Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
Model Number: | W2016012740 |
Minimum Order Quantity: | 1set |
Price: | $5000~$20000 one set |
Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
Delivery Time: | 0-60 days after deposit received |
Payment Terms: | L/C, T/T |
Supply Ability: | 60 sets per month |
Detail Information |
|||
For the past 30 years, Center Enamel has been engaged in the design, manufacture and installation of Glass Lined steel tanks. GLS water tanks are storage solutions for a wide range of industries, including biogas, mining, industrial, fire, agricultural, and municipal applications. Center Enamel have been the market leader in bolted glass fused steel storage solutions for more than 30 years. Our design, manufacture and install glass lined steel tanks for customers worldwide. We adopt advanced modern production methods meet international standards, which ensure the highest quality products.
Center Enamel Co., Ltd is not only the first glass lined water storage tanks manufacturer and supplier in China, but also the most experienced glass lined steel water storage tanks manufacturer in all of Asia. Center Enamel glass lined steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC glass lined steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel glass lined steel tanks have been exported to more than 65 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Glass Lined Steel Water Tanks
After firing at 820°C-930°C high temperature, the molten glass reacts with the steel plate surface to form an inert and inorganic bond,During this period, interaction between the glass and steel accelerates, an interfacial adhesion layer is formed and synthesis of the two materials takes place. Glass-Fused-to-Steel technology is the premium coating technology in the storage tanks market, and glass lined steel tanks are widely used in bio-energy, municipal sewage, landfill leachate and industrial wastewater treatment etc. applications
Glass Lined Steel Water Tanks Specifications
Coating color | dark blue, dark green, white, and customized |
A standard steel plate size | effective size 2400mm x 1200 m |
Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
Adhesion | 3,450N/cm |
Elastic | same as steel sheet, around 500KN/mm |
Hardness | 6.0 Mohs |
Service life | >30 years |
Spark test | >1500 V |
Permeability | gas and liquid impermeable |
Easy yo clean | smooth, glossy, inert, anti-adhesion |
Corrosion resistance | excellent! Suitable for wastewater saltwater, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
Glass Lined Steel Water Tanks Applications
Center Enamel glass lined steel water tanks and are ideal for the following applications:
Process Water Storage
Potable Water Storage
BioEnergy/Anaerobic Digesters
Wastewater Treatment
Leachate Treatment
Glass Lined Steel Water Tanks Projects
