Glass Fused Steel Tanks With Glass Fused Steel Roof For Biogas Plant
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W20161021021 |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
| Delivery Time: | 0-60 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W20161021021 |
| Adhesion: | 3,450N/cm | Holiday Test: | >1500v |
| Foundation: | Concrete Or Glass Fused Steel | Steel Grade: | ART 310 |
| High Light: | glass fused to steel water tanks,above ground fuel storage tanks,Biogas Plant Glass Fused Steel Tanks |
||
Product Description
Glass Fused Steel Tanks With Glass Fused Steel Roof For Biogas Plant
Glass-Fused-to-Steel tank is a unique tank finish. Two materials are fused together to achieve the best properties of both, including the strength and flexibility of steel combined with the corrosion resistance of glass.
Glass-Fused-to-Steel technology is the premium coating technology in the storage tanks market, and Glass Fused To Steel Tank is the leading Water Storage Solutions, which is widely used as Water Storage Tanks for the potable water project, fire protection water storage project, drinking water storage project, wastewater treatment project, biogas project, leachate treatment project etc. With the advantage of both GLASS and STEEL, Glass Fused To Steel Tanks can resist the corrosion of Waste Water of PH 1 - 14.
Applied to both interior and exterior surfaces, Glass-Fused-to-Steel is able to provide many years of trouble-free service in harsh environments. This system has been proven over many decades on thousands of installations. Our Glass-Fused-to-Steel tanks are supported by International Standards, including AWWA D103-09 and EN/ISO28765:2011.
Glass Fused to Steel Tanks Specifications
| Coating color | dark blue, dark green , white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm , depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coating internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet , around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance |
excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds
|
Glass Fused To Steel Tanks Manufacturer
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Glass Fused To Steel Tanks Project References
