Glass Fused To Steel Liquid Storage Tanks With Porcelain Enamel Coating Process

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W
Steel Plates Thickness: 3mm To 12mm , Depends On The Tank Structure Hardness: 6.0Mohs
Steel Grade: ART 310 Foundation: Concrete Or Glass Fused Steel
High Light:

liquid fertilizer storage tanks

,

crude oil storage tank

Product Description

Glass Fused to Steel Liquid Storage Tanks With Porcelain Enamel Coating Process



Glass Fused to Steel Liquid Storage Tanks

Glass fused to steel liquid storage tanks can apply to water supply and treatment and wastewater treatment, such as potable water, Ro water, bitter – brackish water, fire water storage, saltwater, irrigation water, animal wastes etc . Glass fused to steel liquid storage tank is the double-wall coating steel sheet with enamel frits, which can install in indoor, above ground, underground ect . Glass fused to steel liquid storage tank will be connected with special sealant ( waterproof ) and high corrosion bolts, for its rapid installation, great corrosion resistance and low cost of maintenance, which will be famous among tanks, because it greatly solves the problem of traditional tanks such as long-time installation, need big equipment, low corrosion resistance etc .Glass Fused to Steel Liquid Storage Tanks With Beautiful Appearance And Long Service Life







Glass Fused to Steel Liquid Storage Tanks Selected Roofs

1. Glass fused to steel material roof ( tightness roof )

2. Double membrane roof / single membrane roof ( tightness roof )

3. Aluminum deck roof/aluminum dome roof

4. Fiberglass resistance roof





Glass Fused to Steel Liquid Storage Tanks Specifications



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,

salt fox, organic and inorganic compounds









About Center Enamel

Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
