3000000 Gallons Glass Lined Steel Liquid Storage Tanks With Aluminum Alloy Trough Deck Roofs
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden |
| Delivery Time: | 10-30 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
Product Description
3,000,000 Gallons Glass Lined Steel Liquid Storage Tanks With Aluminum Alloy Trough Deck Roofs
What is Glass Lined Steel Liquid Storage Tanks?
Glass Lined Steel Liquid Storage Tanks, also known as Glass-Fused-to-Steel Liquid Storage Tanks, these names all mean the same thing. Glass Lined Steel Liquid Storage Tanks combine the strength and flexibility of steel and the corrosion resistance of glass.
The high-temperature fusion of glass to steel fired at 850°C results in an inert, durable finish. Applied to both interior and exterior, the GFS technology is able to withstand the rigors of the construction site and provide many years of trouble-free service in harsh environments.
Specifications Of Glass Lined Steel Liquid Storage Tanks
| Category | Specification |
| Coating Color | Dark green, or Customizing colors |
| Coating Thickness | 0.25~0.40mm, double coating |
| Acid and alkalinity proof | Standard pH: 3~11, Special pH: 1~14 |
| Adhesion | 3,450N/cm |
| Elastic | Same as steel sheet, around 500kN/mm |
| Hardness | 6.0 Mohs |
| Service life | ≥30 Years |
| Holiday test | >1500V |
| Permeability | Gas liquid-impermeable |
GFS Tank Advantages :
Short construction period, cost-effective tank solution
Superior corrosion resistance, service life is more than 30 years
Easy to install, no need for big installation equipment and/or very skilled labors
Tank volume can be easily expanded
It can be dismantled, removed and relocated
Elegant appearance, tank color can be customized
Accessories:
HDG self-locking bolts & silicon sealant
external HDG vertical ladder with platform
1 set of HDG manway
Design criterion & certificates: :
EN28765, NSF/ANSI 61, ISO9001, FDA, AWWA-D103-09
About Center Enamel
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
