Glass - Fused - To Steel GFS Bolted Storage Tanks For Municipal Wastewater Treatment

large.img.alt
small.img.alt

Large Image :  Glass - Fused - To Steel GFS Bolted Storage Tanks For Municipal Wastewater Treatment

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Coating Thickness: 0.25mm~0.40mm & Double Coating Adhesion: Adhesion
Service Life: ≥30 Years Holiday Test: >1500v
Permeability: Gas / Liquid Impermeable Elastic: Same As Steel Sheet ,around 500KN /mm
Roof Available: Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof Size Of Panel: 2.4M * 1.2M
Acid And Alkalinity Proof: Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14
High Light:

glass fused to steel water tanks

,

above ground fuel storage tanks

Glass-Fused-To Steel GFS Bolted Storage Tanks for Municipal Wastewater Treatment



What is Glass-Fused-to-Steel?



Glass Fused to Steel Bolted Storage tank, These types of bolted tanks are commonly called “glass lined” (GLT), “glass fused-to-steel” (GFS) or “glass coated” (GCT) depending on the region where they are installed, but these names all mean the same thing, that the tank panels are lined inside and out with a glass enamel that binds to the metal providing many advantages over standard epoxy coated or welded painted storage tanks.



This solution utilizes the Glass-Fused-to-Steel finish on both interior and exterior surfaces to give long term protection and the following benefits:



Category Specification
Coating Color Dark green, or Customizing colors
Coating Thickness 0.25~0.40mm, double coating
Acid and alkalinity proof Standard pH: 3~11, Special pH: 1~14
Adhesion 3,450N/cm
Elastic Same as steel sheet, around 500kN/mm
Hardness 6.0 Mohs
Service life ≥30 Years
Holiday test >1500V
Permeability Gas liquid impermeable
Easy to clean Smooth, glossy inert, anti-adhesion
Corrosion resistance Excellent suitable for waste water, salt water, sea water, high suifur crude oil, salt fog, organic and inorganic compounds
Modular bolted tank construction Rapid and cost effective site installation, reducing project timescales, costs and requirement for on-site equipment
Flexibility to remodel Tanks can be extended, dismantled and re-sited giving long term asset value
Maintenance Safe and secure storage, with minimal maintenance costs



Application including:



The Glass Fused to Steel construction of these bolted tanks is exceptional for the storage of potable water, waste water, petroleum, chemicals and dry bulk and in such applications as reservoirs (open top or with aluminum dome or flat panel roof), power generation stations, standpipes, frac processing, fish ponds, sludge tanks, trickling filters, high temp fermentation plants.



Design criterion & certificates:



Our bank design confirms to the standard of OSHA, EN28765, NSF/ANSI 61, ISO9001, FDA, AWWA-D103-09, NSF61 drinking water system.



Who we are?



Center Enamel Co., Ltd was established in 1989, is the pioneer and the largest manufacturer of glass fused to steel tanks in China. CEC Engaged in enamel industry for more than 20 years, focused on enamel frit R&D and achieved more than 200 patents of enamel frit formulas.



CEC Advantages:



Professional R&D Team:



    - 1*Technical Consultant

   National technical expert; Senior engineer; over 50 years enameling R&D experience

   - 23*Advanced Technician

   Postgraduate educational background; expert in enamel R&D over 10 years



 Advanced Production Line

  - Raw material - enamel frit manufacturer

  - CNC cutting machine for steel place

  - Automatic enamel line for spray



Quality Control



 - Raw Material Test: Raw material ingredient analysis, raw material impurity test and etc.

 - Enamel Sample Test: Enamel fluidity test, color difference analysis, firing test, acid and alkali resistance     test, adherence test

 - Destructive Test: Impact test,holiday test, slice microscope analysis

 - Numbering for each steel plate for tracking
