Sludge water holding tanks , bolted steel water storage tanks Large Volume
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W20160127003 |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
| Delivery Time: | 0-60 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W20160127003 |
| Coating Color: | Dark Green / Can Be Customized | Coating Thickness: | 0.25mm~0.40mm & Double Coating |
| Adhesion: | 3,450N/cm | Elastic: | Same As Steel Sheet ,around 500KN /mm |
| Hardness: | 6.0Mohs | Service Life: | ≥30 Years |
| Permeability: | Gas And Liquid Impermeable | High Light: | bolted steel water storage tanks,welded steel tanks |
Product Description
Most Cost Effective Bolted Steel Tanks Sludge Holding Tanks Large Volume
Introduction
Our Bolted Steel Tanks are glass fused to steel tanks, which is mainly composed of steel sheet ,special sealant and the self-locking bolts .It is not complex in structure and easy to ship to the construction site . The prime components of the kit are the glass-fused-to-steel panels, ready for bolting together and complete with any special cut-outs for nozzles and/or manways or other appurtenances as required. The panels overlap and are bolted together and sealed with a high performance seal Our Glass Fused to Steel proprietary bolts are finless and are safe to use with glass fused to steel bolted tanks.. All the bolt heads are plastic-capped to provide corrosion protection in the process environment. Mastic squeezes out between the panels and the bolt head seals the shank and protects it from contact with process fluids. With more than 20 years development, Center enamel already exported to over 20 countries in the world including Belgium, France, Malaysia, Singapore, USA, Niger and so on.
Application of Bolted Steel Tanks
- industrial effluent storage tanks
- Anaerobic digestion and biogas tanks
- Process water tanks
- Food waste treatment tanks
- Brewery and Beverage Waste Tanks
- Desalination tanks
- Bulk solid storage silos
- Leachate storage
- Fish farm tanks
- Firewater tanks
- Tannery effluent tanks
- Scrubber tanks
- Fuel storage
- Hazardous Liquid storage
- Mining process tanks
Why choose glass fused to steel tank
- Impermeable to liquids and gases
- Excellent impact and abrasion resistance
- NSF Approved
- Flexible
- Superior longevity
- No re-painting or re-coating is required
- Excellent chemical resistance
Comparison of various tanks
|
Characteristic |
Cement |
Carbon steel |
Enamel tank |
LIPP tank |
|
Weight (T) |
heavy |
Little heavy |
light |
Little light |
|
Tank cost |
middle |
high |
low |
low |
|
Tank temperature protect |
no |
need |
need |
need |
|
Anti-corrosive Treatment |
no |
need |
no |
need |
|
Annual anticorrosive cost |
no |
High cost |
no |
High cost |
|
Corrosion resistance |
normal |
no |
superior |
normal |
|
Abrasion resistance |
good |
bad |
good |
bad |
|
Service life |
30 |
10 |
30 |
25 |
