Engineered Excellence Center Enamel's Superior Resistance Oil Tank Manufacturing For Welded Steel Tanks
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | J2016012804 |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
| Delivery Time: | 0-60 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | J2016012804 |
| Serive Life: | More Than 30 Years | Coating Color: | Dark Blue, Dark Green , White, And Customized |
| Easy Yo Clean: | Smooth, Glossy, Inert, Anti-adhesion | Coating Thickness: | 4.0.25mm - 0.4mm, Two Coating Internal And External |
| Permeability: | Gas And Liquid Impermeable | Steel Plates Thickness: | 3mm - 12mm , Depends On The Diameter & Height |
| Elastic: | Same As Steel Sheet , Around 500KN/mm | PH: | 1 - 14 |
| Highlight: | Steel Welded Oil Tank,Superior Resistance Oil Tank,Anti-Adhesion Welded Steel Tanks |
||
Product Description
| Attribute | Value |
|---|---|
| Service Life | More than 30 years |
| Coating Color | Dark blue, dark green, white, and customized |
| Easy to Clean | Smooth, glossy, inert, anti-adhesion |
| Coating Thickness | 0.25mm - 0.4mm, two coating internal and external |
| Permeability | Gas and liquid impermeable |
| Steel Plates Thickness | 3mm - 12mm, depends on the diameter & height |
| Elastic | Same as steel sheet, around 500KN/mm |
| PH | 1 - 14 |
In the global oil and gas industry, the integrity and longevity of storage tanks are paramount. Exposure to corrosive crude oils, aggressive refined products, and harsh environmental conditions demands tanks that possess superior resistance from the very moment of their manufacture. At Shijiazhuang Zhengzhong Technology Co., Ltd (Center Enamel), our commitment to this principle is embedded in every stage of our Welded Steel Tank manufacturing for oil storage, ensuring that each tank we produce is a testament to unyielding durability, unparalleled safety, and a significantly extended service life.
While Center Enamel is renowned worldwide as a pioneering leader in advanced bolted tank solutions, particularly our innovative Glass-Fused-to-Steel (GFS) tanks, our expertise and advanced manufacturing capabilities extend comprehensively to the fabrication of high-performance welded steel tanks. These tanks are the workhorses of large-scale crude oil terminals, refineries, and distribution hubs, and it is our meticulous manufacturing process that imbues them with the superior resistance vital for critical petroleum assets.
As a leading storage tank manufacturer worldwide, Center Enamel can provide:
- Glass Lined Steel (GLS) tanks
- Fusion bonded epoxy tanks
- Stainless steel tanks
- Galvanized steel tanks
- Aluminum geodesic dome roofs
- Wastewater and Biogas Project Equipment
| Storage Tanks | Volume | Roofs | Application | Design Requirements |
|---|---|---|---|---|
| GLS Tanks, SS Tanks, Fusion Bonded Epoxy Tanks, Galvanized Steel Tanks, Welded Steel Tanks | <1000m³, 1000-10000m³, 10000-20000m³, 20000-25000m³, >25000m³ | ADR Roof, GLS Roof, Membrane Roof, FRP Roof, Trough Deck Roof | Wastewater Treatment Project, Drinking Water Project, Municipal Sewage Project, Biogas Project, Fire Water Storage Project, Oil Storage Project | Water Supply & Drainage System, Seismic Design, Wind Resistant Design, Lightning Protection Design, Tank Insulation Design |
| Pretreatment Equipment | Resource Utilization System | Sludge Treatment System | Other Equipment |
|---|---|---|---|
| Mechanical Bar Screen, Solid-liquid Separator, Submersible Mixer | Gas Holder, Boiler System, Boost Fan, Bio gas Generator, Torch System, Dehydration and Desulfurization Tank | PAM Integration Dosing Device, Screw Sludge Dewatering Machine, Slurry Separation Centrifuge | Sewage Pump, Mud Scraper, Submersible Sewage Pump, Three-phases Separator |
The exceptional resistance of Center Enamel's welded steel oil tanks begins not at the installation site, but within our advanced manufacturing facilities. Every step is precisely controlled to build in durability and long-term performance.
- Certified Steel: Meticulously sourced high-grade carbon steel plates compliant with API 650, ASTM A283, A516 standards
- Advanced Cutting and Forming: Precision cutting (plasma or laser) and rolling processes for optimal fit-up
- Surface Preparation: Thorough abrasive blasting to NACE #2 / SSPC-SP 6 standards for ideal coating adhesion
- Certified Welders: Highly skilled professionals proficient in SMAW, GMAW, SAW techniques
- Automated Welding Processes: For consistent weld quality and structural integrity
- Non-Destructive Testing: Including Radiographic Testing, Ultrasonic Testing, and Magnetic Particle Inspection
Superior resistance is not just about manufacturing quality; it's also about intelligent design that anticipates and mitigates corrosive forces over the tank's operational life.
Center Enamel's manufacturing processes comply with API 650 and API 620 standards, including provisions for corrosion allowances in material thickness.
- Internal/External Floating Roofs to reduce vapor space and minimize oxygen ingress
- Cone Up/Slope Bottom Designs for efficient drainage of corrosive elements
- Double Bottoms for enhanced leak protection and detection
- Uncompromising Quality Control: Every component meticulously inspected
- Experienced Workforce: Highly skilled engineers and specialists
- Global Project Experience: Successful deliveries in diverse climates worldwide
- Holistic Solutions: From design to post-installation service
- Regulatory Compliance: Meeting and exceeding international standards
