Product Details:
Payment & Shipping Terms:
|
| Tank Body Color: | Dark Green / Can Be Customized | Corrosion Integrity: | Excellent |
|---|---|---|---|
| Steel Plates Thickness: | 3mm To 12mm , Depends On The Tank Structure | Chemical Resistance: | Excellent |
| Size Of Panel: | 2.4M * 1.2M | Easy To Clean: | Smooth, Glossy, Inert, Anti-adhesion |
| High Light: | Bolted Steel Water Storage Tanks,3mm Steel Plates Water Storage Tanks |
||
Every bolted steel potable water storage tank is factory engineered to customer specifications. Since all tank panels are manufactured in the factory and easily assembled, our potable water storage tanks can be easily installed in many types of situations when field-welded steel and concrete applications cannot. We the leader of potable water storage tank manufacturer in Asia.Center Enamel bolted steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC bolted steel tanks are widely used in potable/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications.
FROM THE TOP DOWN, FASTER CONSTRUCTION
Our potable water storage tanks are assembled by our building crews from the top down with a jacking system that progressively elevates the structure without the need of expensive cranes. Erection crews can stay safely on the ground. This construction method enables rapid, logical progress for timely completion.
ROOFS OR DOMES
Our potable water storage tanks roofs and domes can be designed to each customer's needs, taking into account wind, snow loads, seismic and design codes. Including GFS/enamel roof, aluminum alloy trough deck roofs, single and double membrane roofs, FRP roofs, aluminum dome roofs
Bolted Steel Potable Water Storage Tanks Specifications
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
Bolted Steel Potable Water Storage Tanks Manufacturer
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in potable/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Bolted Steel Potable Water Storage Tanks Project References
