|Applications:||Water , Waste Water, Digester , Reactor , Grain , Sludge , Chemicals||Service Life:||≥30 Years|
|Acid And Alkalinity Proof:||PH1 - PH14||Impact Resistance:||Excellent|
|Capactiy Available:||20 M3 To 20,000 M3||Usage:||Waste Water Treatment , Sewage Treatment, Effluent Treatment, Ect.|
bolted steel water storage tanks,
welded steel tanks
300000 Gallons Bolted steel Water Storage Tanks for Commercial And Industrial Fire Protection Water Storage
Bolted steel water storage tanks are a convenient storage solution for commercial and industrial fire protection water storage. They are constructed from individual steel panels that are manufactured and finished at an enclosed facility, then transported to the site and bolted together using the appropriate gaskets and self-locking bolts for the product that will be stored. Unlike conventional concrete or welded storage solutions, which require extensive fabrication and finishing processes on site, bolted tanks offer quick installation, lower shipping costs, and they can be assembled in nearly any type of weather, eliminating many weather-related delays.
When comes to installation, we will send out installation guide to be on site to train the local workers how to assemble the tanks. In contrast, Field-welded steel tanks are welded by trained and licensed welders, which cost a lot of money and time that might otherwise be better spent elsewhere. This results in an installation process that is quick and easy, far faster than the installation of concrete or welded tanks, and it is not subject to the weather delays that often stall the installation of competing designs.
Bolted steel water storage tanks have a large variety of system applications, mainly including fire protection water storage tank, potable water tank, anaerobic digester, biogas tank, dry bulk storage tank, leachate tank, municipal sewage tank, agriculture water tank and industrial wastewater tank.
Bolted steel Water Storage Tanks Specifications
|Coating color||dark blue, dark green, white, and customized|
|A standard steel plate size||effective size 2400mm x 1200 m|
|Steel plates thickness||3mm - 12mm, depends on the diameter & height|
|Coating thickness||0.25mm - 0.4mm, two coatings internal and external|
|Acid and alkalinity proof||standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14|
|Elastic||same as steel sheet, around 500KN/mm|
|Service life||>30 years|
|Spark test||>1500 V|
|Permeability||gas and liquid impermeable|
|Easy yo clean||smooth, glossy, inert, anti-adhesion|
|Corrosion resistance||excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,
salt fox, organic and inorganic compounds
About Center Enamel
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
