Bolted Sewage / Waste Water Tank For Chemical Plant / Food Processes Fire Protection
| Place of Origin: | CHINA |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W20180508011 |
| Minimum Order Quantity: | 1 SET |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates;wooden pallet and wooden box |
| Delivery Time: | 10-30 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | CHINA | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W20180508011 |
| Coating Color: | Dark Green, White, Blue, Color Can Be Customized Upon Your Request | Acid And Alkalinity Proof: | Standard Sheet PH: 3 - 11 Special Sheet PH: 1 - 14 |
| Holiday Test: | > 1500 V | Permeability: | Gas / Liquid Impermeable |
| Service Life: | ≥ 30 Years | Corrosion Resistance: | Excellent. Suitable For Waste Water Treatment, Sewage Treatment, Effluent Treatment |
| High Light: | commercial water storage tanks,municipal water storage tanks |
||
Product Description
Bolted Sewage / Waste Water Tank applied in Chemical Plant / Food Processes / Fire Protection
Glass Fused To Steel Tanks are the leader of Water Storage Solutions, which is widely used as Water Storage Tanks for Potable Distribution Line, Bio Gas Plant, Waste Water Treat Plant (WWTP) etc. With the advantage of both GLASS and STEEL, Glass Fused To Steel Tanks can resist corrosion of Waste Water of PH 1 - 14.
Center Enamel Co., Ltd., as the largest and most professional manufacturer and supplier of Glass Fused To Steel Tanks in China, have been engaged in the industries for more than 25 years, since its establishment at 1989. Center Enamel GFS tanks comply with ANSI/AWWA D103 latest version, EN ISO 28765 and NSF-61 standard, products have been exported to over 20 countries successfully.
Comparison between GFS Tank and Various Tanks
| Item | Concrete Tank | Carbon steel tank | Enamel tank (Glass-fused-to-Steel tanks) |
LIPP tank |
| Beautiful degree | Low | Low | High | High |
| Temperature adaption | A stress |
Adapt to low temperature |
Adapt to low temperature |
Adapt to low temperature |
| Shape | Any shape | Round shape | Round shape | Round shape |
| Ground Or underground | Both | Ground | Both | Ground |
| Corrosion resistance | Normal | No resistance to corrosion | Good | Not |
| Abrasion resistance | Good | Bad | Good | Bad |
| Easy to clean | Bad | Bad | Good | Normal |
| Easy to repair | Normal | Good | Good | Bad |
| Weight (T) | heavy | Little heavy | light | Little light |
| Tank cost | middle | high | low | low |
| Tank temperature protect | no | need | need | need |
| Anti-corrosive Treatment | no | need | no | need |
| Annual anti-corrosive cost | no | High cost | no | High cost |
| Corrosion resistance | normal | no | superior | normal |
| Abrasion resistance | good | bad | good | bad |
| Service life | 30 | 10 | 30 | 25 |
Specification of Glass Fused To Steel Tanks
| Category | Specification |
| Coating Color | Dark green, white, blue, color can be customized upon your request |
| Coating Thickness | 0.25 - 0.40mm, double coating |
| Acid and alkalinity proof | Standard sheet PH: 3 - 11 |
| Special sheet PH: 1 - 14 | |
| Adhesion | 3450 N / cm |
| Elastic | Same as steel sheet, around 500 Kn / mm |
| Hardness | 6.0 ( Mohs ) |
| Service life | ≥ 30 Years |
| Holiday test | > 1500 V |
| Permeability | Gas / liquid impermeable |
| Easy to clean | Smooth, glossy, inert, non adhesive |
| Corrosion resistance |
Excellent. Suitable for waste water treatment, sewage treatment, effluent treatment |
