Product Details:

Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20161020003

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Contact Now
Detailed Product Description
Service Life: ≥30 Years Capacity: 20 M3 To 18,000 M3
Coating Thickness: 0.25mm~0.40mm , Two Layer Of Coating Internal And External Tank Material: Glass Fused To Steel
Chemical Resistance: Excellent Corrosion Integrity: Excellent

Superior Corrosion Resistance Glass Lined Steel Tanks , Long Service Life





Introduction of Glass Lined Steel(GLS) Tanks



Glass Lined Steel Tanks consist of enamel sheet, special sealant,self-locking bolts and other accessories. And among them , enamel sheet is the most important part. Enamel sheet is finished where Glass and Steel are fused together to achieve the best of both: strength and flexibility of the steel combined with superior corrosion resistance of the glass.



GLS tanks can be used as vessel for many kinds of water storage, such as the resort wastewater storage,the town wastewater storage, potable water storage,fire protection water storage, rain water storage etc.



Specification of Glass Lined Steel Tanks



Category Specification
Coating Color dark green, white, blue and also color can be customized
Coating Thickness 0.25 - 0.40mm , double coating
Acid and alkalinity proof Standard pH: 3 - 11
Special pH: 1 - 14
Adhesion 3450 N / cm
Elastic Same as steel sheet, around 500 kN / mm
Hardness 6.0 ( Mohs )
Service life ≥ 30 Years
Holiday test > 1500 V
Permeability Gas / liquid impermeable
Easy to clean Smooth, glossy, inert, anti-adhesion
Corrosion resistance Excellent,suitable for water storage, waste water treatment, sewage treatment, high sulfur crude oil,salt fox,organic and inorganic compounds



Superior Corrosion Resistance Glass Lined Stainless Steel Water Storage Tanks , Long Service Life



Main Advantage of GLS Tanks



  1. Short installation period : compare to more than 40days installation time for other type tanks, usually GLS tanks only needs even less than 15days.
  2. Superior corrosion resistance : GLS tanks can resist pH rage 1-14.
  3. Beautiful appearance : Standard color is dark green, and color can be customized according to customer’s request.
  4. Climate adaptability : GLS tanks can be used in almost all kinds of weather conditions, that is very important for some special areas.
  5. Long service life : more than 30 years service life.
  6. Easy construction : No requirement for big installation equipment, and can be easily expand, dismantle and move

Quality Control



Raw Material Test --- Raw material ingredient analysis, raw material impurity test and etc.

Enamel Sample Test ---Enamel fluidity test, color difference analysis, firing test, acid and alkali resistance test, adherence test

Destructive Test --- Impact test,holiday test, slice microscope analysis





Project Reference



2008 Beijing Olympic Games Sewage Treatment -- 4 sets of Ф18.33×3.6M,1 set of Ф4.82×3.6M

Niger Water Storage Tanks Project -- 2 sets of Ф19.86×4.8M,1 set of Ф9.93×4.2M, 3 sets
of Ф9.93×3.6M;

Australia Drinking Water Project -- 2 sets of Ф22.17×6M;

Ecuador Potable Water Storage Project -- 6 sets of Ф18.34×4.8M
