Glass Fused To Steel Leachate Storage Tanks dark green Acid Resistant

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20160127023
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W20160127023
Erection Expense: Low PH Range: 1~14
Corrosion Integrity: Excellent Chemical Resistance: Excellent
Relocation Capability: Yes Freight Cost: Low
High Light:

water holding tanks

,

aluminium dome roof storage tanks

Product Description

Acid Resistant Glass Fused Leachate Storage Tanks With Over 30 Years Span Life





Introduction of Leachate Storage Tanks

Leachate is the liquid that seeps through solid waste in the landfill and extracts soluble, dissolved and suspended materials in the process. This highly corrosive liquid needs to be properly managed and store, to prevent the leachate contaminated water from seeping into the ground water prior to treatment.



There are only few tanks that have abilities to store landfill leachate, which with the variability in composition. When a project comes with leachate storage tanks, the landfill operator’s first option is Center Enamel’s glass fused to steel leachate storage tanks.



Acid Resistance Test of GFS Leachate Storage Tanks

1. 10% citric acid solution

2. Place on the overlapping of three filter paper 3cmx3cm, use a dropper to drop the 10% citric acid solution,

3. After 15 minutes at room temperature 20 - 25℃, remove the filter paper and rinse with water.

4. Check the enamel surface



Impact Test of GFS Leachate Storage Tanks

1. Test the adhesive ability of glassed lined sheet

2. Put the enameled steel on the base of hydropress, close decompression valve

3. Make hydropress pressing up to 15MPa



GFS Leachate Storage Tanks Set and Accessories

Center Enamel’s glass fused to steel tanks are manufactured and designed as per AWWA D103 - 09 standard, OHSA, and can meet European and Australia design standard.



1. Glass fused to steel sheets

2. Special Sealant

3. Self-locking bolts

4. Manholes

5. Ladder and Platform

6. Roofs and Covers

7. Walkways



Features of Glass Fused To Steel Leachate Storage Tanks

Category

Specification

Coating Color

dark green, white, blue, color can be customized upon your request

Coating Thickness

0.25 - 0.40mm , double coating

Acid and alkalinity proof

Standard sheet  PH: 3 - 11

Special sheet  PH: 1 - 14

Adhesion

3450 N / cm

Elastic

Same as steel sheet, around 500 Kn / mm

Hardness

6.0 ( Mohs )

Service life

≥ 30 Years

Holiday test

> 1500 V

Permeability

Gas / liquid impermeable

Easy to clean

Smooth, glossy, inert, non adhesive

Corrosion resistance

Excellent.

suitable for waste water treatment, sewage treatment, effluent treatment



Project Showroom

During its development in more than 20 years, Center Enamel has exported and built 1000 units of glass fused to steel tanks to over 20 countries, below are some featured projects for your information.



1. 2008 Beijing Olympics Games Waste Water Treatment Project

4 sets of sedimentation tanks Ø18.33x3.6mH

1 set of mud collection tank Ø4.82x3.6mH

Total volume: 5200m3



2. 2010 Palm Oil Mill Effluent Treatment Project in Indonesia

3 sets of Ø19.86x8.4mH

Total Volume: 7800m3
