BSCI Fusion Bonded Epoxy Tanks Environmental Protection Projects For Landfill Leachate

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: J2016012311
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number J2016012311
PH Range: A Grade Sheet PH:3-11, AA Grade Sheet PH : 1-14 Coating Thickness: Two Coating Internal And External
Corrosion Resistance: Excellent ! Suitable For Waste Water Salt Water, Sea Water, High Sulfur Crude Oil, Salt Fox, Organic And Inorganic Compounds Adhesion: 3,450N/cm
Permeability: Gas And Liquid Impermeable Serive Life: More Than 30 Years
High Light:

BSCI Fusion Bonded Epoxy Tanks

,

Landfill Leachate Fusion Bonded Epoxy Tanks

Product Description

Fusion Bonded Epoxy Tanks help environmental protection projects, Center Enamel is the first choice for landfill leachat



As a leading enterprise in Asia's enamel assembled tank industry and a high-quality provider of environmentally friendly EPC and anaerobic process section services, Center Enamel has always been committed to unremitting innovation and development in the field of environmental protection. The company continues to explore innovative solutions for water treatment and leads the water treatment field towards high-quality development. Years of innovation efforts have enabled the company to accumulate many leading technologies and rich experience in the field of water treatment, provide more professional and reliable solutions to global customers based on international standards, and win the trust and praise of customers.



The epoxy resin tank adopts advanced epoxy coating technology, which is not only technologically leading, but also performs well in terms of cost performance. It is easy and quick to install, and its quality meets the requirements of AWWA D103-09, ISO 9227 and ASTM B117 standards. It has been highly recognized by customers as soon as it was launched. This advanced epoxy resin tank technology not only provides superior performance, but also provides customers with a convenient and reliable solution that meets the latest standards and needs in the current environmental protection field.





Properties of Fusion-Boned Epoxy Steel Tanks

Application Test Standard Result
Coating Color Standard RAL 5015 sky blue Other colors are available
Dry Film Thickness Average Dry Thickness 5~10 miles /125 ~250 microns(internal)
5~10 miles /125 ~250 microns(epoxy primer+ topcoat)
Holiday Test ≥1100V (all panels) Zero-discontinuity at test voltage
Hot water immersion 90 days, 70° AWWA C550-05 Meets/exceeds standard
Corrosion Resistance Salt Spray ISO 9227/ASTM B117 Pass
Impact Resistance ASTM D2794 Pass 160 in-ibs direct & reverse impact
PH Range 3~12
Abrasion Resistance Adhesion ASTM D3359 Adhesion ASTM D3359
Hardness ISO15184 / ASTM D3363 2H
Chemical Immersion test 50% NaOH, 50% H2S04 Meets/exceeds industry standard
UV Resistance outdoor exposure testing 5 years
Color Stability outdoor exposure testing 5 years







Introduction to epoxy tank coating
inner coating

Our epoxy is one of the most durable epoxy coatings compared to other epoxies available on the market.
High voltage testing is performed on each sheet to ensure there are no defects under the test voltage.
Optimal control of exterior coating overspray enables interior coatings to comply with drinking water regulations.
Coatings undergo and must pass many different types of tests to ensure high performance and compliance with international quality standards.
Interior surfaces are factory electrostatic powder coated, providing high quality and a consistent even finish.

outer coating

The exterior coating is a combination of epoxy primer and ultra-durable polyester topcoat.
The outer coating undergoes and must pass many different types of tests to ensure high performance and compliance with international quality standards.


The formulation adheres to appropriate controls on substances, allowing the coating to achieve the highest global safety and environmental performance certifications.



From south to north, from east to west, from domestic to foreign countries, Center Enamel projects now roof 90 countries around the world. Center Enamel will also continue to leverage its core advantages in technology, equipment, and services to provide customers with more advanced and reliable water treatment solutions, and will strengthen cooperation with domestic and foreign partners to continuously promote the innovation and application of water treatment technology.
