Glass Fused To Steel Water Liquid Storage Tanks With Corrosion Resistance

Glass Fused To Steel Water Liquid Storage Tanks With Corrosion Resistance
Glass Fused To Steel Water Liquid Storage Tanks With Corrosion Resistance

Large Image :  Glass Fused To Steel Water Liquid Storage Tanks With Corrosion Resistance

Product Details:

Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20161227001

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Adhesion: 3,450N/cm Service Life: ≥30 Years
Holiday Test: >1500v Elastic: Same As Steel Sheet ,around 500KN /mm
Capacity: 20 M3 To 18,000 M3 Coating Thickness: 0.25mm~0.40mm , Two Layer Of Coating Internal And External
High Light:

0.25mm Coating Liquid Storage Tanks

,

18000 m3 Liquid Storage Tanks

Glass Fused to Steel Water & Liquid Storage Tanks with Excellent Corrosion Resistance

In the liquid storage tanks industry, Center Enamel is the leading manufacturer and provides glass fused to steel tanks for customers all over the world. Our liquid storage tanks use the premium coating technology in the storage tanks industry, the glass fused to steel technology. After firing at 820°C-930°C , the steel plate and enamel first fused together and form an inert and inorganic bond, which combines the strength and flexibility of steel and the outstanding corrosion resistance of glass



Our Liquid Storage Tanks are the leader of liquid storage solutions, which is widely used as Water Storage Tanks for Potable Distribution Line, Bio Gas Plant, Waste Water Treat Plant (WWTP) etc. Glass lined liquid storage tanks combine the strength and flexibility of steel and the corrosion resistance of glass., Glass lined liquid tanks can resist corrosion of Waste Water of PH 1 - 14.



Glass Fused to Steel Water & Liquid Storage Tanks Specifications



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,
salt fox, organic and inorganic compounds





Advantages of the Glass Fused to Steel Water & Liquid Storage Tanks

1. Short construction period

2. Superior corrosion resistance, service life is more than 30 yeas

3. Low project cost

4. Tank volume can be easily expanded

5. Beautiful appearance, color can be customized

6. Not subject to weather conditions

7. No need big installation equipment

8. Easily expand, dismantle, move



Glass Fused to Steel Water & Liquid Storage Tanks Manufacturer - Center Enamel



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 65 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India, and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
