Place of Origin: | China |
Brand Name: | CEC TANKS |
Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
Model Number: | W20160504018 |
Minimum Order Quantity: | 1set |
Price: | $5000~$20000 one set |
Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
Delivery Time: | 0-60 days after deposit received |
Payment Terms: | L/C, T/T |
Supply Ability: | 60 sets per month |
Detail Information |
|||
Place of Origin | China | Brand Name | CEC TANKS |
---|---|---|---|
Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W20160504018 |
Coating Thickness: | 0.25mm~0.40mm , Two Layer Of Coating Internal And External | Tank Material: | Glass Fused To Steel |
Corrosion Integrity: | Excellent | Chemical Resistance: | Excellent |
High Light: | condensate storage tank,aluminium dome roof storage tanks |
Glass Fused to Steel Landfill Leachate Storage Tanks For Taizhou Government Landfill Leachate Treatment Projects
This is the Taizhou government landfill leachate treatment project which built-in 2018, there are totally of 7 Glass-Fused-to-Steel tanks with FRP roofs used as landfill leachate storage tanks. This landfill leachate treatment project uses an anaerobic digestion process to treat the landfill leachate. The reactor pool is made of glass fused to steel tanks produced in Center Enamel, which has excellent anti-corrosive performance and can fully meet the requirements for the storage of landfill leachate. It is worth mentioning that the anaerobic digestion reactor of this project is partitioned in the form of tank casing, which has the advantages of compact structure and space-saving. At present, the landfill leachate of the project is discharged to the standard.
Glass Fused to Steel Landfill Leachate Storage Tanks
By burning at over 850°C furnace, the glass coating bonds with the steel plate. The compilation of two material- glass coating and steel - is not just physical but also chemically bonding. Seeing from the microscope, you will see the coating permeates into steel. Other than painted steel tank which will peel off after a period, a glass-coated steel tank does not need to paint at Jobsite. It needs minimum maintenance during the lifetime . Besides, other than welded steel tanks whose installation needs skilled welders, a glass-coated steel tank does not need skilled laborers. It can be installed with no big equipment and unskilled laborers. It is the most cost-effective landfill leachate storage tank.
Landfill Leachate Storage Tanks Specifications
Coating color | dark blue, dark green , white, and customized |
A standard steel plate size | effective size 2400mm x 1200 m |
Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
Adhesion | 3,450N/cm |
Elastic | same as steel sheet, around 500KN/mm |
Hardness | 6.0 Mohs |
Service life | >30 years |
Spark test | >1500 V |
Permeability | gas and liquid impermeable |
Easy yo clean | smooth, glossy, inert, anti-adhesion |
Corrosion resistance |
excellent! Suitable for wastewater saltwater, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds
|
Landfill Leachate Storage Tanks Manufacturer
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Landfill Leachate Storage Tanks Project Reference
