Glass Fused To Steel Landfill Leachate Storage Tanks For Government Landfill Leachate Treatment Projects

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20160504018
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W20160504018
Coating Thickness: 0.25mm~0.40mm , Two Layer Of Coating Internal And External Tank Material: Glass Fused To Steel
Corrosion Integrity: Excellent Chemical Resistance: Excellent
High Light:

condensate storage tank

,

aluminium dome roof storage tanks

Product Description

Glass Fused to Steel Landfill Leachate Storage Tanks For Taizhou Government Landfill Leachate Treatment Projects



This is the Taizhou government landfill leachate treatment project which built-in 2018, there are totally of 7 Glass-Fused-to-Steel tanks with FRP roofs used as landfill leachate storage tanks. This landfill leachate treatment project uses an anaerobic digestion process to treat the landfill leachate. The reactor pool is made of glass fused to steel tanks produced in Center Enamel, which has excellent anti-corrosive performance and can fully meet the requirements for the storage of landfill leachate. It is worth mentioning that the anaerobic digestion reactor of this project is partitioned in the form of tank casing, which has the advantages of compact structure and space-saving. At present, the landfill leachate of the project is discharged to the standard.



Glass Fused to Steel Landfill Leachate Storage Tanks



By burning at over 850°C furnace, the glass coating bonds with the steel plate. The compilation of two material- glass coating and steel - is not just physical but also chemically bonding. Seeing from the microscope, you will see the coating permeates into steel. Other than painted steel tank which will peel off after a period, a glass-coated steel tank does not need to paint at Jobsite. It needs minimum maintenance during the lifetime . Besides, other than welded steel tanks whose installation needs skilled welders, a glass-coated steel tank does not need skilled laborers. It can be installed with no big equipment and unskilled laborers. It is the most cost-effective landfill leachate storage tank.



Landfill Leachate Storage Tanks Specifications



Coating color dark blue, dark green , white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent! Suitable for wastewater saltwater, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds





Landfill Leachate Storage Tanks Manufacturer



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.



Landfill Leachate Storage Tanks Project Reference



Glass Fused To Steel Landfill Leachate Storage Tanks For Government Landfill Leachate Treatment Projects 0
