Payment & Shipping Terms:
|Material:||Glass Fused To Steel||Foundation:||Concrete Or Glass Fused Steel|
|Steel Grade:||ART 310||Roof:||Can Be Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof|
|Service Life:||Over 30 Years|
700000 Gallon Liquid Storage Tanks For Potable Water Storage Projects
In liquid storage containers, quality and value drive today's tank selection process. With advances in manufacturing technology, engineering design, coating techniques, and field construction techniques, Glass-Fused-to-Steel technology is the premium coating technology in the storage tanks market. Our glass fused to steel liquid storage tanks are widely used in water potable water storage projects.
What Is Glass Fused to Steel Liquid Storage Tanks
By burning at over 850°C furnace, the glass coating bonds with the steel plate. The compilation of two material- glass coating and steel - is not just physical but also chemically bonding. Seeing from the microscope, you will see the coating permeates into steel. Other than painted steel tank which will peel off after a period, a glass-coated steel tank does not need to paint at Jobsite. It needs minimum maintenance during the lifetime . Besides, other than welded steel tanks whose installation needs skilled welders, a glass-coated steel tank does not need skilled laborers. It can be installed with no big equipment and unskilled laborers. It is the most cost-effective liquid storage tank.
Liquid Storage Tanks Specifications
|Coating color||dark blue, dark green , white, and customized|
|A standard steel plate size||effective size 2400mm x 1200 m|
|Steel plates thickness||3mm - 12mm , depends on the diameter & height|
|Coating thickness||0.25mm - 0.4mm, two coating internal and external|
|Acid and alkalinity proof||standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14|
|Elastic||same as steel sheet , around 500KN/mm|
|Service life||>30 years|
|Spark test||>1500 V|
|Permeability||gas and liquid impermeable|
|Easy yo clean||smooth, glossy, inert, anti-adhesion|
excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds
Liquid Storage Tanks Manufacturer
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Liquid Storage Tanks Project Reference
Contact Person: Miss.Melody wong
Permeability: as and liquid impermeable
Acid and alkalinity proof: standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Usage: waste water treatment , sewage treatment, effluent treatment, ect.
Corrosion resistance: excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds
