700000 Gallon Liquid Storage Tanks For Potable Water Storage Projects

700000 Gallon Liquid Storage Tanks For Potable Water Storage Projects
700000 Gallon Liquid Storage Tanks For Potable Water Storage Projects

Large Image :  700000 Gallon Liquid Storage Tanks For Potable Water Storage Projects

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20160504007
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Material: Glass Fused To Steel Foundation: Concrete Or Glass Fused Steel
Steel Grade: ART 310 Roof: Can Be Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof
Service Life: Over 30 Years
High Light:

liquid fertilizer storage tanks

,

crude oil storage tank

700000 Gallon Liquid Storage Tanks For Potable Water Storage Projects



In liquid storage containers, quality and value drive today's tank selection process. With advances in manufacturing technology, engineering design, coating techniques, and field construction techniques, Glass-Fused-to-Steel technology is the premium coating technology in the storage tanks market. Our glass fused to steel liquid storage tanks are widely used in water potable water storage projects.



What Is Glass Fused to Steel Liquid Storage Tanks



By burning at over 850°C furnace, the glass coating bonds with the steel plate. The compilation of two material- glass coating and steel - is not just physical but also chemically bonding. Seeing from the microscope, you will see the coating permeates into steel. Other than painted steel tank which will peel off after a period, a glass-coated steel tank does not need to paint at Jobsite. It needs minimum maintenance during the lifetime . Besides, other than welded steel tanks whose installation needs skilled welders, a glass-coated steel tank does not need skilled laborers. It can be installed with no big equipment and unskilled laborers. It is the most cost-effective liquid storage tank.



Liquid Storage Tanks Specifications



Coating color dark blue, dark green , white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm , depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coating internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet , around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds





Liquid Storage Tanks Manufacturer



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.



Liquid Storage Tanks Project Reference



700000 Gallon Liquid Storage Tanks For Potable Water Storage Projects 0
