Center Enamel Glass Lined Steel Storage Tank For Wastewater Treatment Projects

China Center Enamel Glass Lined Steel Storage Tank For Wastewater Treatment Projects supplier

Large Image :  Center Enamel Glass Lined Steel Storage Tank For Wastewater Treatment Projects

Product Details:

Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Contact Now
Detailed Product Description
Tank Body Color: Dark Green / Can Be Customized Corrosion Integrity: Excellent
Steel Plates Thickness: 3mm To 12mm , Depends On The Tank Structure Chemical Resistance: Excellent
Size Of Panel: 2.4M * 1.2M Easy To Clean: Smooth, Glossy, Inert, Anti-adhesion

Center Enamel Glass Lined Steel Wastewater Storage Tank For Wastewater Treatment Projects



Glass-Lined-Steel is a unique tank finish. Glass lined steel wastewater storage tanks provide steel strength with corrosion resistant glass, inside and outside. Glass-Lined-Stee is not strictly a coating, but a combination of the two materials that provides excellent life protection in almost all water and wastewater applications. It has also been variously described as glass lined steel (GLS), glass coated steel (GCS) or glass enamel steel , but it is nevertheless described as the ultimate solution for tanks and silos.

Center Enamel is internationally recognized as the world's leading manufacturer of glass lined steel tanks. All inner surfaces are 100% inspected by the factory to further improve product quality. Glass-Fused-to-Steel is able to provide many years of trouble free service in harsh environments. This system has been proven over many decades on thousands of installations, and is supported by International Standards which cover the design and finish requirements.



Glass Lined Steel Wastewater Storage Tank Specififcations



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,
salt fox, organic and inorganic compounds



About Center Enamel



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.



Project References



Center Enamel Glass Lined Steel Storage Tank For Wastewater Treatment Projects
