Glass Fused To Steel Liquid Fertilizer Storage Tanks 30 Years Service Life

Glass Fused To Steel Liquid Fertilizer Storage Tanks 30 Years Service Life
Glass Fused To Steel Liquid Fertilizer Storage Tanks 30 Years Service Life

Large Image :  Glass Fused To Steel Liquid Fertilizer Storage Tanks 30 Years Service Life

Product Details:
Place of Origin: CHINA
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20180508003
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates;wooden pallets and wooden box
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Coating Color: Dark Green, Or Customizing Colors Coating Thickness: 0.25~0.40mm, Double Coating
Acid And Alkalinity Proof: Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14 Adhesion: 3,450N/cm
Hardness: 6.0 Mohs Holiday Test: >1500V
Installation: By Jacking Machine Or Steel Pole, Fast In Installation Permeability: Gas / Liquid Impermeable
Foundation: Concrete Or Glass Fused Steel Steel Grade: ART 310
Applications: Water , Waste Water, Digester , Reactor , Grain , Sludge , Chemicals
High Light:

liquid fertilizer storage tanks

,

crude oil storage tank

30 Years Service Life Glass Fused to Steel Liquid Fertilizer Storage Tanks for Sale







Brief Introduction Of Glass Fused to Steel Liquid Fertilizer Storage Tanks



Glass fused to steel liquid fertilizer storage tank is a kind of factory fabrication tank, which made of glass fused to steel plates. After firing at 820°C-930°C high temperature, the molten glass reacts with the steel plate surface to form an inert and inorganic bond, which combines the strength and flexibility of steel and outstanding corrosion resistance of glass, so Glass-Fused-to-Steel tanks can provide many advantages over standard epoxy or weld painted storage tanks. And all glass fused to steel liquid fertilizer storage tanks for sale have long service life for more than 30 years. High recommended, all of the holes on the tank wall will be prosecuted on the workshop, instead of on job site. According to the size of the hole , there will be some flanges nozzles along with.



About the installation of glass fused to steel tank, there is no need big equipment to do it. Jacks are required during the installation, we will install the tank from the top ring, one by one until all of them are installed . Glass fused to steel tank is widely used in wastewater treatment, sludge treatment anaerobic digester, because of its’s excellent corrosion resistance.



Glass Fused to Steel Liquid Fertilizer Storage Tanks Specifications

1. Type: Glass fused to steel liquid tank

2. Color: Cobalt blue, green, sky blue, or custom color3. Roof: Glass fused to steel roof, aluminum dome roof, aluminum deck roof, fiberglass roof.

4. Size: Tank size up to 18000m3 , will be larger in the near future .

5. Service Life : More than 30 years , better than traditional tank like concrete tank

6. PH range: Standard sheet PH:3-11 , Special sheet PH : 1-14

7. Holiday test: More than 1500V

8. Corrosion resistance: Excellent, suitable for wastewater, saltwater, seawater, high sulfur crude oil, salt fog, organic and inorganic compounds

9. Hardness: 6.0 Mohs

10. Elastic: Same as steel sheet, around 500 KN/mm

11. Adhesion : 3,450 N/cm



30 Years Service Life Glass Fused to Steel Liquid Fertilizer Storage Tanks for Sale
