0.25mm ~ 0.40mm Double Coating Liquid Gas Storage Tank From 20m³ To 20,000m³

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W
Coating Thickness: 0.25mm~0.40mm & Double Coating Adhesion: 3,450N/cm
Hardness: 6.0Mohs Service Life: ≥30 Years
Permeability: Gas / Liquid Impermeable Tank Body Color: Dark Green / Can Be Customized
Roof Available: Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof Acid And Alkalinity Proof: Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14
High Light:

chemical storage tank

,

crude oil storage tank

Product Description

30+ Years Service Life Liquid Storage Steel Tanks from 20m³ to 20,000m³



Center Enamel Co., Ltd provides liquid storage tank with capacity from minimum to maximum 20,000m3 . We design and manufacture the tank according to America standard “AWWA D-103/09 Factory Coated Bolted Steel Tanks from Water Storage” . The designed lifespan of our liquid storage tank is over 30 years . The so-called liquid storage tank we provide is glass-fused-steel tanks ( GFS tanks ) , in some places, it is also named vitrified steel tanks , or glass lined steel tanks ( GLS tanks) .



To choose Center Enamel’s liquid storage tank , you will achieve the following advantages:



1. No need crane or other large equipment during erection
2. not subjected to severe weather and environment
3. customized color , can match with surrounding buildings
4. smooth and glossy out-appearance , free from graffiti
5. minimal maintenance cost
6. . superior performance in corrosion resistance and against rust
7. factory fabrication tank . No painting or spray on erection site
8. can be designed to future expansion, dismantle or re-movement.
9. free service for technical drawings including foundation connection
10. turn key service from proposal to tank commissioning





There are not just only one type of bolted tanks . Actually, bolted tanks could be galvanized steel bolted tank, stainless steel bolted tank , epoxy steel bolted tank , and last but not the least glass fused steel bolted tanks . Among them , epoxy tanks and glass steel tanks are two type of tanks which are most probably be mixed up .



tank

item

Glass Fused Steel Bolted Tank Epoxy Steel Bolted Tank
Furnace temperature 850-900°C Over 200°C
Bonding type Chemical and physical bonding , coating permeates into raw steel Physical adhesion , coating and raw steel are still two separated material
UV resistance Color inert , UV resistance Not as inert as glass coating, will degraded by UV
Maintenance Does not need repainting at site It will delaminate ofpeels off after several years of UV . So re-painting is needed ( approx. every 5 years)





Specification of Center Enamel’s Liquid Storage Tanks :

1. Coating Color : standard dark blue and dark green . Moreover , colors can be customized.

2. Thickness of coating : 0.25~0.45mm , double coating. 2 layers of enamel coating forms superfine glass foam-like structure of the enameling layer , enable the materials' excellent flexibility and durability.

3. Acid and alkalinity proof : Standard sheet PH : 4~11; Special sheet PH : 1~14.

4. Adhesion : 3450 N / cm

5. Elastic : Same as steel sheet, around 500 Kn / mm.

6. Hardness : 6.0 ( Mohs )

7. Service life : The super performance of the glass fused to steel sheet offer a long lifespan in excess of 30 years

8. Holiday test ( spark test) : > 1500v

9. Permeability : Gas / liquid impermeable. It’s very suitable for waste water treatment, biogas digester.

10. Corrosion resistance : Excellent. suitable for waste water treatment , sewage treatment , effluent treatment , salt water ,sea water , high-sulfur crude oil , salt fox , organic and inorganic compounds.

11. Capacity : Wide range from 20 m3 to 18000 m3. Moreover , the tanks can be expanded and remodel easily.





Application of our Liquid Storage Tanks :

1. Water supply and Treatment : Potable water , Bitter-brackish water , Raw water / Fresh water, Aeration , Biological Filter , Water Purifying , Fire-fighting water , Saline Water / Brine Water , Ro Water , Irrigation water, Sea water desalinization , Clarification Pool.

2. Wastewater Treatment : Buffer Pool , Aerobic Reacto , Biological Filter , Effluent Treatment , Regulating Tank , Anaerobic reactor , Leachate Storage , , Water Purifying , Sedimentation Container , Sludge Tank , Animal Wastes storage



Reference completed Projects Worldwide

  • 2 ( two) Industrial waste water plants total 7 tanks at Sakhalin Island of Russia , Built at 2016 and 2017
  • Leachate Containment – Oregon, USA, Ø 29.81*7.2m , built in August 2016
  • Potable Water Storage tanks – Canada Yuko, 2 pc of 12.23*5.4m, built at 2018
  • Raw water and production water tank – water production factory at Manta Ecuador , 6 pcs of 1250m3 built at January 2016
  • Textile waste water treatment plant at Ethiopia, 23 tanks total volume 44,000m3 , built at 2018
  • Coco-Cola Plant Wastewater Treatment, Malaysia Ø7.64*17.4m and Ø9.17*16.8m , built in October, 2016
