Enamel Coated Steel Grain Storage Silos Corrosion Resistance

Enamel Coated Steel Grain Storage Silos Corrosion Resistance
Enamel Coated Steel Grain Storage Silos Corrosion Resistance Enamel Coated Steel Grain Storage Silos Corrosion Resistance

Large Image :  Enamel Coated Steel Grain Storage Silos Corrosion Resistance

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: J2016012704
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Acid And Alkalinity Proof: Standard Sheet PH:3~11 Special Sheet PH: 1~14 Hardness: 6.0Mohs
Holiday Test: >1500v Design Life: 50 Years
Capacity: 20 M3 To 18,000 M3 Tank Body ColorDark Green / Can Be Customized: Dark Green / Can Be Customized
Coating Thickness: 0.25mm~0.40mm , Two Layer Of Coating Internal And Exteral Elastic: Same As Steel Sheet ,around 500KN /mm
Adhesion: 3,450N/cm
High Light:

50000 gallon water storage tanks

,

glass lined steel tanks

 10,000 Tons Grain Storage Silo With Excellent Corrosion Resistance





Process of glass fused to steel grain storage silo



First step : get raw material and measure the thickness with micrometer to check whether it matches raw material to be used

Second step : cutting , corner cut and edging , put the steel sheet on the laser cutting machine as per data which set in the computer according to the contract

Third step : press arc , according to the diameter , determine the radian of the pressure plate

Fourth step : short blasting , shifting the steel grit and add it to the blasting machine , hoist the rough steel into the blasting machine

Fifth step : Glaze mortar adjustment according to specification

Sixth step : Spray , before spraying , check the plate is clean and no defects , use sandpaper to clean the surface well and then put them into the automatic spray machine , start spraying

Seventh step : burning , after finish spray put the steel sheet to the high temperature oven , the burning temperature between ground enamel and top enamel are different

Eighth step : production QC , chemical elements inspection ; holiday test ; Coating thickness gauge ; Out appearance checking ; Anti-acid & alkali test ; Anti-high temperature test ; Adhesion test ; Adhesion test





Superiority of the Glass fused to steel tank



1. Glass fused to steel tanks provide the durability and strength of ART 310 steel sheet with the acid and alkali proof of glass , interior and exterior .

2. Glass lined is not strictly a coating but also a fusion of the two materials , offering excellent protection in almost any water and wastewater applications .

3. Glass fused to steel tanks are designed to provide decades of trouble free service in harsh environment.

4. Glass fused to steel tanks are anti-leaking of gas and liquid, make it suitable for various kind of gas and liquid storage, such as industrial effluent, sewage, wastewater, portable water, biogas and so on.

5. The glass fused to steel tanks are bolted tanks that makes it expandable, removable, easily installed and dismantle.

6. Color can be customized





Specification of glass fused to steel silo



Coating Color

Dark green , white , blue ,color can be customized

Coating Thickness

0.25mm - 0.40mm,double coating

Acid and Alkali proof

Standard sheet PH: 3-11
Special sheet PH: 1-14

Adhesion

3450N/CM

Elastic

Same as steel sheet , around 500 KN/MM

Hardness

6.0(Mohs)

Service Life

More than 30 year

Holiday Test

More tank 1500V

Permeability

Gas/Liquid impermeable

Easy to clean

Smooth , glossy , inert , non adhesive

Corrosion resistance

Excellent , suitable for wastewater , salt water , sea water , high-sulfur crude oil , salt fox , organic and inorganic compounds
