Vitrum Anaerobic Digester Tank / Organic Waste Digester Glass Fused To Steel Bolted

Vitrum Anaerobic Digester Tank / Organic Waste Digester Glass Fused To Steel Bolted
Vitrum Anaerobic Digester Tank / Organic Waste Digester Glass Fused To Steel Bolted Vitrum Anaerobic Digester Tank / Organic Waste Digester Glass Fused To Steel Bolted

Large Image :  Vitrum Anaerobic Digester Tank / Organic Waste Digester Glass Fused To Steel Bolted

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: J2016012639
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Coating Color: Customized Roof Type: Glass Steel Roof, Membrane Roof, Aluminum Roof, GRP Roof
Design According To: AWWA D 103 , OSHA Tank Color: Dark Green, Dark Blue, Light Blue And Customized
Tank Material: Glass Coated Steel Sheets Capacity Range: 20 M3 To 18,000 M3
Service Life: More Than 30 Years Coating Thickness: 0.35mm
High Light:

anaerobic sludge digester

,

anaerobic manure digester

Vitrum Bolted Glass Fused To Steel Anaerobic Digester Tank







What is glass fused to steel tank ?



The steel round (cylindrical) shell of the tank is built from two - layer enameled sheets coated on both sides . The sheets are attached with special high-grade bolts and sealed by constantly flexible silicone (sealant) . The surface of connecting material and the shell itself are properly treated .



This is the only tank finish where two materials are fused together to achieve the best of both : the strength and flexibility of the steel combined with the corrosion resistance of the glass . The high temperature fusion of glass to steel fired at 850 degree results in an inert , durable finish . Applied to both interior and exterior , the GFS technology is able to withstand the rigorous of the construction site and provide many years of trouble free service in harsh environments .



Specification



Steel plates thickness : 3mm - 12mm , depends on the diameter & height

Coating thickness : 0.25mm - 0.4mm, two coating internal and external

Acid and alkalinity proof : standard coating suits for PH3 - PH11 , special  coating suits for PH1 - PH14

Adhesion : 3,450N/cm

Elastic : same as steel sheet , around 500KN/mm

Hardness : 6.0 Mohs

Service life :  >30 years

Spark test  :  >1500 V

Permeability : gas and liquid impermeable

Easy yo clean : smooth , glossy , inert , anti-adhesion





Application of AD tank



Anaerobic digesters are utilized in many situations where industrial or agricultural operations produce a significant organic waste stream . In addition , municipal solid waste ( MSW ) landfills produce landfill gas from natural decomposition of organic material in the waste that can be captured for use as an energy source . Many MSW sites now have wells to capture biogas produced from waste decomposition . Wastewater treatment plants  ( WWTPs )  can also be converted to operate anaerobically , and they can be used to produce biogas from a variety of wastes .





Technical Advantages



  • Being engaged in enamel industry since 1989 ( for over 26 years ) , we process more than 200 patents of enamel frit formulas . Enamel frit supply to the world top 500 company
  • Complied with quality system certificate ISO9001-2008 , glass – fused – to - steel tank manufacturing standard Q/01ZT012009 and NSF ( National Sanitation Foundation) .
  • We make structure design of GFS tank according to AWWA D103-09 and OSHA.
