6.0Mohs 20m3 Biogas Storage Tanks For Food Waste Project

6.0Mohs 20m3 Biogas Storage Tanks For Food Waste Project
6.0Mohs 20m3 Biogas Storage Tanks For Food Waste Project 6.0Mohs 20m3 Biogas Storage Tanks For Food Waste Project 6.0Mohs 20m3 Biogas Storage Tanks For Food Waste Project 6.0Mohs 20m3 Biogas Storage Tanks For Food Waste Project

Large Image :  6.0Mohs 20m3 Biogas Storage Tanks For Food Waste Project

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Service Life: ≥30 Years Acid And Alkalinity Proo: Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14
Capactiy Available: 20 M3 To 20,000 M3 Usage: Waste Water Treatment , Sewage Treatment, Effluent Treatment, Ect.
Corrosion Resistance: Suitable For Waste Water Salt Water, Sea Water, High Sulfur Crude Oil, Salt Fox, Organic And Inorganic Compounds Foundation: Concrete Or Glass Fused Steel
High Light:

20m3 Biogas Storage Tanks

,

6.0Mohs Biogas Storage Tanks

Biogas Storage Tanks For Food Waste Biogas Project



The use of anaerobic digestion (AD) to treat food waste and other materials is now a well-established technology used in the global region. Center Enamel has been in the AD field for over 30 years; we design, manufacture and install AD tanks for our customers, supporting the global challenge of reducing waste and generating more renewable green energy. Let's explore how the anaerobic digestion process works and the benefits of using it in more detail.



The biogas produced by the anaerobic digestion plant is composed of combustible gas methane (50-75%), carbon dioxide (25-50%), water (H2O), nitrogen (N2), oxygen (O2), hydrogen sulfide (H2S), ammonia ( NH3) and trace elements (organohalides, siloxanes, etc.). H2S, CO2 and water make biogas very corrosive.



Whether you're battling greenhouse gases or rising energy costs, Center Enamel can help you build an anaerobic digester that will last.Our main products include Glass-Fused-to-Steel tanks, stainless steel tanks, Carbon Steel tanks, aluminum geodesic dome roofs, and can provide customized design, manufacturing, and installation for global customers.



Glass Fused to Steel Biogas Tank Specifications



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,
salt fox, organic and inorganic compounds





Center Enamel is the leading bolted tanks and roofs manufacturer in China, which have more than 30 years of industry experience. All our products are in strict accordance with AWWA D103-09, API 650, OSHA, ISO 28765, NSF/ANSI 61, NFPA and other international standards. Until 2022, Center Enamel storage tanks and roofs have been exported to more than 90 countries including the USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, Brazil, and South Africa etc.
