Anti - Adhesion Glass Fused Steel Tanks For Biogas Project

large.img.alt
small.img.alt

Large Image :  Anti - Adhesion Glass Fused Steel Tanks For Biogas Project

Product Details:
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Detailed Product Description
Impact Resistance: Excellent Installation: By Jacking Machine Or Steel Pole, Fast In Installation
Tank Material: Glass Fused To Steel Hardness: 6.0Mohs
Steel Grade: ART 310
High Light:

Anti - Adhesion Glass Fused Steel Tanks

,

Biogas Glass Fused Steel Tanks

,

500KN/mm Biogas Storage Tank

Glass-Fused-to-Steel Tanks for Biogas Project

The use of anaerobic digestion to generate biogas is increasingly recognized as a valuable method of using waste to generate renewable energy.

Glass-fused-to-Steel tanks can be used in medium-temperature digesters, high-temperature digesters, and various other sewage treatment processes. Almost any organic waste can be digested, and biogas projects now use a large amount of food processing waste, household waste, and restaurant waste. More and more urban sludge effluent and farm waste (such as animal waste) are digested together to produce "green" renewable energy.



GFS Tanks Specifications



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,

salt fox, organic and inorganic compounds





The biogas produced by the biogas project can be purified and directly introduced into the power grid, or it can be converted into electricity by a generator using a combined heat and power engine. At the end of anaerobic digestion, you can consider using the digested materials as fertilizer to increase the potential source of income for the project.

Modular design allows flexible adaptation to various aspect ratios, process pressures and temperatures to adapt to various AD processes, designs and applications specified by process designers.

The GLS plate is used not only for the tank wall, but also for the tank top to form a sealed anaerobic fermentation tank. This provides a high degree of protection for the Glass-Fused-to-Steel in the entire anaerobic fermentation tank, especially in the highly corrosive gaseous area. The structural design of these roofs allows for local environmental loads and can also support a centrally installed mixer system.

In addition, the FRP tank can also be used for biogas storage by combining with a double membrane cover. Our enamel assembly tank is a combination of the strength of steel and the flexibility of a modular structure, which has significant advantages compared with other types of anaerobic digestion tank structures.



About Center Enamel Co., Ltd



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc.
