| Foundation: | Concrete Or Glass Fused Steel | Steel Plates Thickness: | 3mm To 12mm , Depends On The Tank Structure |
|---|---|---|---|
| Roof Available: | Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof | Easy To Clean: | Smooth, Glossy, Inert, Anti-adhesion |
| Feature: | Eco-friendly, Durability | Capactiy Available: | 20 M3 To 18,000 M3 |
| High Light: | 18000m3 Glass Lined Steel Tank,Seawater Glass Lined Steel Tank,Saltwater Glass Lined Steel Tank |
||
Glass Lined Steel tank For Municipal sewage Treatment Projects
With the rapid development of global economy, the problem of environmental pollution, especially the treatment of municipal sewage has become a research hotspot in many countries. municipal sewage is the outcome of city development. With the development of urbanization and industrialization, its output has been increasing, and the pollution has become increasingly serious, which has seriously restricted the sustainable development of urban economy.
As a storage tank for municipal sewage treatment, Glass lined steel Tank has become the preferred choice of municipal sewage storage solution in municipal sewage treatment plant of each city.
Why the municipal sewage treatment plant choose Glass Lined Steel Tank?
The service life is more than 30 years with a lower maintenance, Glass-Fused-to-Steel is two materials - Enamel glaze and steel plate surface are fused together after heat treatment at 850-940℃ and then create a tough and inert bond, which combines the strength of steel with the outstanding chemical and physical corrosion resistance of glass. Then it is easy to install , dismantled, removed and relocated, Glass Lined Steel tank is assembled by Glass-Fused-To-Steel plate and fixed by self - locking bolt. Then the sealing glue is applied to the joint gap and bolt position to improve airtightness of the tank. Also tank’s color can be customized ,which enable Glass-Fused-to-Steel tank better integrate with the surrounding environment. That is why so many municipal sewage treatment plant choose Glass Lined Steel Tank as the municipal sewage storage tank.
Glass Lined Steel Specifications
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater saltwater, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
Glass Lined Steel Tanks Manufacturer
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2021, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 80 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
Glass Lined Steel Tanks Project References
