Customized Glass Fused To Steel Anaerobic Digester Tank With Super Corrosion Resistance
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden |
| Delivery Time: | 10-30 days after deposit received |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
Product Description
Customized Glass Fused To Steel Anaerobic Digestion Tanks With Super Corrosion Resistance
The glass fused to steel anaerobic biogas digester is a process which decomposes and converts the organic waste into biogas gas, the biological process is called anaerobic digester. The digester reaction needs to do it in some conditions, the decomposition needs to accomplish in the absence of oxygen environment, airtightness environment will be selected as a reactor . In order to achieve full reaction agitator and heating system are required, there is also some temperature requirements during the reaction , mesophiles are most efficient at moderate temperature ranges between 25°C - 40°C while thermophiles run most efficiently at higher ranges between 45°C - 80° C.
Customized glass fused to steel anaerobic digestion tanks are made of glass fused to steel which is superior in corrosion resistant as it is actually the combination of “ glass ” and “ steel “. So it has the advantages of both: superior corrosion resistance of glass, and strength and flexibility of steel. This is the combination of both to achieve the best . Glass fused steel tank is the best tank to be used as an anaerobic reactor, especially when the media inside than tank could be highly corrosive.
The high-temperature fusion of glass to steel fired at 800-950 degree results in an inert, durable finish. Applied to both interior and exterior, the GFS technology is able to withstand the rigorous of the construction site and provide many years of trouble-free service in harsh environments.
Specification of Glass Fused To Steel Anaerobic Digestion Tanks
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
