Steel Anaerobic Reactor With Pvc Membrane , Generate Biogas Storage Tank for Water Treatment Plant

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20180103007
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 10-30 days after deposit received
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W20180103007
Foundation: Concrete Or Glass Fused Steel Steel Plates Thickness: 3mm To 12mm , Depends On The Tank Structure
Corrosion Integrity: Excellent Chemical Resistance: Excellent
Size Of Panel: 2.4M * 1.2M Capactiy Available: 20 M3 To 18,000 M3
High Light:

anaerobic sludge digester


anaerobic manure digester

Product Description

Steel Anaerobic Reactor With Pvc Membrane Gas Holder To Generate Biogas for Water Treatment Plant with AWWA D103 International Standard



Glass lined steel tank with geo membrane roof is tank who are used for the storage of Biogas and therefore are covered by the biogas double membrane roof. The biogas double membrane roof exist from a inside membrane from biogas persistent foil and a weather persistent outside membrane. Both membranes are mounted on the tankwall with hot dip galvanized hooping . On the inside a steel centre column with a net and tensioned bands hold the double membrane roof. Standard the roof is made for lower pressures -0.5 en Pmax 5 mbar, on request higher pressures can be designed. We deliver several volumes depending on diameter tanks up to 32 meters.


Steel anaerobic reactor can be used at the following applications:


Municipal: In the municipal environment these tanks are used for drinking water, municipal waste leachate storage, sewage treatment, wastewater treatment and anaerobic digestion

Industrial: Industrial applications catered for include industrial effluent storage and process, industrial effluent digestion, process water storage and bulk solids storage

Agricultural: For agriculture, Glass-Fused-to-Steel Tanks & Silos are utilized for slurry storage, farm biogas production and grain and forage silos

Mining: The tough chemical and abrasion resistance of PERMASTORE® Glass-Fused-to-Steel Tanks & Silos make them ideal for storage and process applications

Bio-fuels: As well as biogas applications, these tanks can be used within the bio-fuels market for vegetable oils, bio-diesel and ethanol storage


Comparison between GFS Tanks and Concrete Tanks


1. Easy Construction: All the tank shells of Glass-Fused-To-Steel Tanks are factory coated, can be easily assembled and installed in difficult conditions, to meet the urgency requirement of project, unlike Concrete Tanks will be affected seriously by bad weather and other factors.


2. Corrosion Resistance: Concrete tank would corroded through to reinforcing bar within 5 years of installation, Glass-Fused-To-Steel Tanks with 2 layer of Glass coating, can be applied for PH from 3 to 11, Center Enamel also provide 2 Years Warranty of its Glass-Fused-To-Steel Tanks.


3. Leakage and Maintenance: Concrete is susceptible to cracking so that many Concrete Tanks show signs of visible leaks and require substantial remedial maintenance, Glass-Fused-To-Steel Tanks are an excellent alternative with less maintenance due to the steel strong tension strength.


Center Enamel Co. Ltd ‘s steel anaerobic reactor meets or exceeds the following internationally comparable requirements:


EEA 7.20

AWWA D-103/9





Project reference :


2500m3 potable water storage tank , Melbourne, Australia , year 2015

3 pcs anaerobic reactor for palm oil wastewater biogas plant, Sandakan, Malaysia , year 2009

3 pcs 300m3 municipal waste water storage tank in Colombia , year 2016

300m3 dairy effluent storage tank in Christchurch , New Zealand, year 2016

Filtered water storage tank in Wallen Australia , year 2015

6 pcs. 1500m3 glass fused steel tank for water treatment plant , year 2015


Steel Anaerobic Reactor With Pvc Membrane , Generate Biogas Storage Tank for Water Treatment Plant 0Steel Anaerobic Reactor With Pvc Membrane , Generate Biogas Storage Tank for Water Treatment Plant 1


Below are also available accessories / parts for customer’s option:


1. Manholes

2. Walkways

3. Working Platform

4. Ladders

5. Nozzles


Glass lined steel tank application :


Substrate treatment Residual waste storage
Energy storage system Bulk material storage
Rain reservoir Water tank
Buffer tank Waste water tank
Sludge holding tank Aeration basin
Tricking filter plant Secondary settling tank
Mixing and surge tank fermenter
Landfill leachate storage Process vessel
Fire protection system Grain silo
Agriculture irrigation system Anaerobic digester
