ART 310 Steel Grade Grain Storage Silos , 30 Years Service Life
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, AWWA D103 , OSHA , BSCI |
| Model Number: | W20171219005 |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
| Delivery Time: | 10-30 days after deposit received |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, AWWA D103 , OSHA , BSCI | Model Number | W20171219005 |
| Size Of Panel: | 2.4M * 1.2M | Acid And Alkalinity Proof: | Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14 |
| Corrosion Integrity: | Excellent | Steel Grade: | ART 310 |
| Defect Free: | Minimum Maintenance Needed | Warranty Period: | 2 Years Free Of Charge |
| High Light: | 50000 gallon water storage tanks,steel potable water storage tanks |
||
Product Description
Grain Storage Silos Storage Solutions for Dry Bulk & Liquid Solution
What is Glass Fused to Steel Tanks?
Glass-Fused-to-Steel (Glass-Lined-Steel) is a unique tank finish. Two materials are fused together to achieve the best properties of both – the strength and flexibility of steel combined with the corrosion resistance of glass. Applied to both interior and exterior surfaces, Glass-Fused-to-Steel is able to provide many years of trouble free service in harsh environments.
Specification:
| Category | Specification |
| Coating Color | Dark green, or Customizing colors |
| Coating Thickness | 0.25~0.40mm, double coating |
| Acid and alkalinity proof | Standard pH: 3~11, Special pH: 1~14 |
| Adhesion | 3,450N/cm |
| Elastic | Same as steel sheet, around 500kN/mm |
| Hardness | 6.0 Mohs |
| Service life | ≥30 Years |
| Holiday test | >1500V |
| Permeability | Gas liquid impermeable |
GFS Tank Advantages :
- Long life
- Low capital cost
- Low maintenance costs
- Rapid installation
- Ease of transport to site
- Flexibility to re-model, extend, dismantle and relocate
Accessories:
HDG self locking bolts & silicon sealant
external HDG vertical ladder with platform
1 set of HDG manway
Tank Roof Optional:
-Glass Fused to Steel Tank Roof
-Double Membrane Roof
- Aluminum Deck Roof
- Aluminum Dome Roof
- FRP / GRP Roof
Design criterion & certificates:
This system has been proven over many decades on thousands of installations, and is supported by International Standards which cover the design and finish requirements:
OSHA, EN28765, NSF/ANSI 61, ISO9001, FDA, AWWA-D103-09
Tank Size Chart:
CEC full range of Tanks are available in the sizes listed in the table below:
Application Fields including:
GFS tanks used in fire protection, irrigation, agricultural, industrial, mining, potable drinking water and many other applications.
Who we are?
Center Enamel Co., Ltd has been manufacturing and installing a complete line of bolted steel tanks and enamel storage tanks for the potable water, wastewater, fire protection, rain harvesting and bio energy digester Industries since 1989.
CEC Advantages:
- R&D Ability
With nearly 30 years experience in enameling industry, Center Enamel Co.,Ltd has become the largest and most professional enamel tank manufacturer in China.
We already established a professional R&D team and advanced laboratory. With this strong enameling R&D ability, we can meet various demands of customers.
- Advanced Production Line - CNC & Automatic production machine
- Quality Control
- Raw Material Test.
- Enamel Sample Test
- Destructive Test
- Acid and Alkali Resistance Test
- 1500V Holiday Test
- Adherence Test
- Enamel Thickness Test
Project reference
