5,800 Gallons Agricultural Water Storage Tanks With Alkalinity Proof

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20171219001
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 10-30 days after deposit received
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W20171219001
Corrosion Integrity: Excellent Size Of Panel: 2.4M * 1.2M
Roof Available: Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof Acid And Alkalinity Proof: Standard Coating Suits For PH3 - PH11, Special Coating Suits For PH1 - PH14
Easy To Clean: Smooth, Glossy, Inert, Anti-adhesion Feature: Eco-friendly, Durability
High Light:

grain storage tanks

,

large capacity water storage tanks

Product Description

5,800 Gallons Agricultural Water Storage Tanks Solve Your Storage Needs







What is Agricultural Water Storage Tanks?



Glass-Fused-to-Steel (GFS), also known as Glass-Lined-Steel (GLS) and Agricultural Water Storage Tanks, these names all means the same thing. This is the only tank finish where two materials are fused together to achieve the best of both: the strength and flexibility of the steel combined with these corrosion resistance of the glass. The high temperature fusion of glass to steel fired at 850°C results in an inert, durable finish. Applied to both interior and exterior, the GFS technology is able to withstand the rigours of the construction site and provide many years of trouble free service in harsh environments.



Specification:



Category Specification
Coating Color Dark green, or Customizing colors
Coating Thickness 0.25~0.40mm, double coating
Acid and alkalinity proof Standard pH: 3~11, Special pH: 1~14
Adhesion 3,450N/cm
Elastic Same as steel sheet, around 500kN/mm
Hardness 6.0 Mohs
Service life ≥30 Years
Holiday test >1500V
Permeability Gas liquid impermeable





GFS Tank Advantages :



- Short construction period, low project cost;

- Superior corrosion resistance, service life is more than 30 years;

- Convenient installation, easy construction, good quality;

- Tank volume is easily expanded;

- Beautiful appearance, color can be customized;

- Not subject to weather conditions;

- No need big installation equipment;

- Easily expand, dismantle, move;



The product is manufactured from high quality corrugated, hot-dipped galvanized steel for superior strength and durability. CEC Tank is engineered to withstand the wind and snow loads and seismic forces at specific locations to ensure longevity of the tank. Intensive engineering to national design codes makes these tanks extremely adaptable to any climate, landscape type or building facility. Unique to the customer's needs and assembled at the project site.



Accessories:



HDG self locking bolts & silicon sealant

external HDG vertical ladder with platform

1 set of HDG manway



Tank Roof Optional:



- Glass Fused to Steel Tank Roof

- Double Membrane Roof

- Aluminum Deck Roof

- FRP / GRP Roof



5,800 Gallons Agricultural Water Storage Tanks With Alkalinity Proof 0



Design criterion & certificates:



OSHA, EN28765, NSF/ANSI 61, ISO9001, FDA, AWWA-D103-09



Tank Size Chart:

CEC full range of Tanks are available in the sizes listed in the table below:



5,800 Gallons Agricultural Water Storage Tanks With Alkalinity Proof 1



Application Fields including:



GFS tanks used in fire protection, irrigation, agricultural, industrial, mining, potable drinking water and many other applications.



Who we are?

Center Enamel Co., Ltd has been manufacturing and installing a complete line of bolted steel tanks and enamel storage tanks for the potable water, wastewater, fire protection, rain harvesting and bio energy digester Industries since 1989.





CEC Advantages:

  • R&D Ability

With nearly 30 years experience in enameling industry, Center Enamel Co.,Ltd has become the largest and most professional enamel tank manufacturer in China.

We already established a professional R&D team and advanced laboratory. With this strong enameling R&D ability, we can meet various demands of customers.



  • Advanced Production Line - CNC & Automatic production machine



  • Quality Control
  1. Raw Material Test.
  2. Enamel Sample Test
  3. Destructive Test
  4. Acid and Alkali Resistance Test
  5. 1500V Holiday Test
  6. Adherence Test
  7. Enamel Thickness Test



Project reference



5,800 Gallons Agricultural Water Storage Tanks With Alkalinity Proof 2
