Glass lined bolted chemical holding tanks , anaerobic waste water treatment

China Glass lined bolted chemical holding tanks , anaerobic waste water treatment  supplier
Glass lined bolted chemical holding tanks , anaerobic waste water treatment  supplier Glass lined bolted chemical holding tanks , anaerobic waste water treatment  supplier

Large Image :  Glass lined bolted chemical holding tanks , anaerobic waste water treatment

Product Details:

Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W20160127006

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Contact Now
Detailed Product Description
Elastic: Same As Steel Sheet ,around 500KN /mm Hardness: 6.0Mohs
Service Life: More Than 30 Years Permeability: Gas And Liquid Impermeable
Coating Color: Dark Green / Can Be Customized Coating Thickness: 0.25mm~0.40mm & Double Coating

Glass Lined Bolted Liquid Storage Tank Used In Wastewater Treatment Process





How to do the wastewater treatment ?

As you know if we discharge wastewater directly , then the earth will be polluted our health is threatened . There is many bacterias and other dangerous materials in the wastewater . Doing the wastewater treatment , many bacterias will be moved , there is no danger to human health or unacceptable damage to the natural environment .



Wastewaster treatment , the first process is doing pretreatment , the purpose is to remove the large solid from the wastewater . The next step is primary treatment , which need clarification and sedimentation tank to finish this process , the purpose is to remove the suspended solid and biochemical particulated from the wastewater .



After finished the pretreatment and primary treatment , it need to do the secondary treatment . For the secondary treatment , it require anerobic mircroorganisms facilities ( most of the wastewater treatment use this facility to do the wastewater treatment ) to do it. The purpose of it is to remove the remaining suspended solid and BOD . Wastewater treatment facilities utilize anaerobic digester ( Glass fused to steel anaerobic digester tank ) to break down sewage sludge and eliminate pathogens in wastewater .



Compartion of kinds of tanks

Item

Concrete Tank

Carbon steeel tank

Enamel  bolted tank

LIPP tank

Beautiful degree

Low

Low

High

High

Temperature adaption

A stress

Adapt to low temperature

Adapt to low temperature

Adapt to low temperature

Shape

Any shape

Round shape

Round shape

Round shape

Above ground or underground

Both

Above ground

Both

Above ground

Corrosion resisitance

Normal

No resist to corrosion

Good

Not

Abrasion resisitance

Good

Bad

Good

Bad

Easy to clean

Bad

Bad

Good

Normal

Easy to repair

NOmal

Good

Good

Bad



Center Quality Control

* Raw materials testing in the factory:ingredient analysis, impurities test;

* Recipe finalized small samples test : enamel fluidity test, chromatic     difference analysis, enamel burning experiment , acid and alkali resistance testing, glossy, adhesion etc,

* Middle stage products test :amplification experiment simulated  environment;

* Destructive testing, detection , impact test,  sparks test, sliced electric microscope analysis .



Technology advantages

* Being engaged in enamel industry for over 26 years , we process more than 200 patents of enamel frit formulas .



* Complied with quality system certificate ISO9001-2008 , glass – fused – to - steel tank manufacturing standard Q/01ZT012009 and NSF ( National Sanitation Foundation ) .



* We make structure design of GFS tank according to AWWA D103-09 , OSHA Europe standards and Australia standards .
