PH14 Biogas Storage Tank For UASB Process In Pig Wastewater Treatment Projects

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W
Tank Material: Glass Fused To Steel Foundation: Concrete Or Glass Fused Steel
Steel Grade: ART 310 Roof Available: Glass Fused Steel Roof , Membrane Roof, Aluminum Roof , GRP Roof
Corrosion Integrity: Excellent Chemical Resistance: Excellent
Elastic: Same As Steel Sheet ,around 500KN /mm High Light:

PH14 Biogas Storage Tank

,

UASB Biogas Storage Tank

Product Description

Biogas Storage Tank For UASB Process in Pig Wastewater Treatment Projects



The digestion of waste, animal manure and energy crops by farms is seen as an important part of the growth of global "green" renewable energy solutions. Anaerobic digestion (AD) is considered an ideal system for processing waste sludge, which can generate farm income and improve the fertilizer performance of the sludge. In addition, the digestion of energy crops is rapidly becoming a viable commercial diversification for farmers

The long history and experience of anaerobic digesters can be traced back to the early 1970s

Glass melting steel can be used in both liquid and gaseous areas, thereby reducing project costs and maximizing the service life of the storage tank structure. The corrosion resistance of the glass steel welding suitable for the digester and the auxiliary water tank can be provided Long-term security, thereby reducing operation and maintenance costs

Our farm biogas storage tank is made of glass-melted steel, so we call it glass-melted steel storage tank, which combines the strength and flexibility of steel with the corrosion resistance of glass. Compared with standard epoxy resin storage tanks and welding paint storage tanks, GFS biogas storage tanks have many advantages. Our biogas digester has a service life of more than 30 years.

GFS biogas digesters have made a positive contribution to the production of renewable energy and environmental protection. Our glass melting steel biogas storage tank design has been tested and verified for decades, and has now become an indispensable feature in the design of any modern sewage treatment plant in the world. As a leading supplier of biogas storage tanks, we maintain the value chain as long as possible in our own company.

Farm Biogas Storage Tank Specifications





Coating color dark blue, dark green , white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm , depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coating internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet , around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds







The advantage of GFS Biogas Storage Tank



1. Advanced technology and innovative edge protection ensure that the storage tank with the center enamel glass fused to the steel is a special solution in the harshest storage environment.

2. Center Enamel glass fused steel storage tank has strong corrosion resistance and can be used in liquid and gas areas to maximize the service life of the storage tank structure.

3. The customized color makes the tank coordinate with the surrounding environment.

4. Long service life, low maintenance, and reduce the risk and loss of closing the project during operation.

5. Modular bolt structure, simple installation tools, short installation period.

6. The tank can be disassembled and transformed, so that the product has continuous asset value.



Farm Biogas Storage Tank Manufacturer



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.



GFS Biogas Storage Tank Project References




PH14 Biogas Storage Tank For UASB Process In Pig Wastewater Treatment Projects 0
