Corrosion Resistant Liquid Storage Tanks For Potable Drinking Water Residential

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: W
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden
Delivery Time: 10-30 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number W
Tank Material: Glass Fused To Steel Foundation: Concrete Or Glass Fused Steel
Steel Plates Thickness: 3mm To 12mm , Depends On The Tank Structure Size Of Panel: 2.4M * 1.2M
Easy To Clean: Smooth, Glossy, Inert, Anti-adhesion Permeability: Gas / Liquid Impermeable
High Light:

3mm Steel Liquid Storage Tanks

,

Glossy Liquid Storage Tanks

Product Description

Corrosion Resistant Liquid Storage Tank for potable (drinking) water for Residential and Commercial applications



Our liquid storage tanks are highly reusable for water and wastewater storage applications. The right storage solutions for Municipal Water & Wastewater Municipalities and utilities depend on proper water and wastewater treatment.The aboveground water storage tanks range from 20m3, up to 25000 m3. The ability to hold potable water in reserve is essential for any and all households, communities, cities and counties to use on an as-needed basis for daily needs. Our tanks are an effective, economical way to store potable (drinking) water for Residential and Commercial applications.



Center Enamel liquid storage tank can be used for storage of gas, oil, water, and petrochemical products, employed for industrial uses. Industrial storage tanks come in different sizes and colors. Center Enamel designs, manufacture and install glass lined steel industrial liquid storage tanks for more than 30 years. Our systems are suitable for all stages of wastewater treatment including mixing tanks, flocculation tanks, sedimentation tanks and others. After firing at 820°C-930°C high temperature, the molten glass reacts with the steel plate surface to form an inert and inorganic bond, which combines the strength and flexibility of steel and outstanding corrosion resistance of glass, so Glass-Fused-to-Steel tanks can provide many advantages over standard epoxy or welded painted storage tanks. Glass-Fused-to-Steel technology is the premium coating technology in the storage tanks market, and Glass-Fused-to-Steel tanks are widely used in bio-energy, municipal sewage, landfill leachate and industrial wastewater treatment etc. Applications.



Glass lined steel industrial liquid storage tanks Specifications



Coating color dark blue, dark green , white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm , depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coating internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet , around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds





Glass lined steel industrial liquid storage tanks Manufacturer



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.



Glass fused to steel industrial liquid storage tanks Project References


Corrosion Resistant Liquid Storage Tanks For Potable Drinking Water Residential 0
