ISO Approved Glass Fused To Steel Liquid Storage Tanks
| Place of Origin: | China |
| Brand Name: | CEC TANKS |
| Certification: | ISO 9001:2008, NSF - 61 , AWWA D103 , OSHA , BSCI |
| Model Number: | W20160831001 |
| Minimum Order Quantity: | 1set |
| Price: | $5000~$20000 one set |
| Packaging Details: | PE poly-foam between each two steel plates ; wooden pallet and wooden box |
| Delivery Time: | 30 days after deposit received |
| Supply Ability: | 60 sets per month |
|
Detail Information |
|||
| Place of Origin | China | Brand Name | CEC TANKS |
|---|---|---|---|
| Certification | ISO 9001:2008, NSF - 61 , AWWA D103 , OSHA , BSCI | Model Number | W20160831001 |
| Foundation: | Concrete Or Glass Fused Steel | Tank Body: | Glass Fused To Steel |
| Service Life: | ≥30 Years | Holiday Test: | >1500v |
| Tank Material: | Glass Fused To Steel | Corrosion Integrity: | Excellent |
| High Light: | Fused Steel Liquid Storage Tanks,sludge Liquid Storage Tanks,500KN/mm Glass Fused Steel Tanks |
||
Product Description
Easy Maintenance And ISO Approved Glass Fused To Steel Liquid Storage Tanks
Glass fused steel tanks are used in a variety of liquid storage applications. Drinking water, wastewater, balanced treatment, sludge, landfill leachate, brine, drip filters, continuous batch reactors (SBR), frac storage, aerobic and anaerobic digesters are just some of the many applications that benefit from the use of this type of tank.
There are several advantages to using glass fused to steel tanks to store liquid storage, corrosive and other liquid applications. In addition to being easy to assemble, they offer greater lifetime value, lower maintenance costs, and less environmental impact than other liquid storage tanks. Over the past decades, they have installed tens of thousands of devices around the world for municipal and industrial applications, and they have an extensive track record of proven performance. The glass-to-steel technique, also known as the enamel process, offers its benefits, applications and conformance to test standards.
Glass Fused to Steel water storage tank Specifications
| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance |
excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds
|
About Center Enamel Co., Ltd
Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
