High Air Tightness Farm Biogas Digester Capacity 20m3 - 25000m3

Product Details
Place of Origin: China
Brand Name: CEC TANKS
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Model Number: J2016012654
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $5000~$20000 one set
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Delivery Time: 0-60 days after deposit received
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month

Detail Information

Place of Origin China Brand Name CEC TANKS
Certification ISO 9001:2008, AWWA D103 , OSHA , BSCI Model Number J2016012654
Adhesion: 3,450N/cm Elastic: Same As Steel Sheet ,around 500KN /mm
Acid And Alkalinity Proof: Standard Sheet PH:3~11 Special Sheet PH: 1~14 Service Life: ≥30 Years
Permeability: Gas And Liquid Impermeable Material: Glass And Steel
Coating Color: Can Be Customized Coating Thickness: 0.25mm~0.40mm & Double Coating
High Light:

25000m3 Farm Biogas Digester

,

glass steel Farm Biogas Digester

Product Description

High air tightness Farm Biogas Digester With Capacity From 20m3 - 18000m3



Farm biogas digesters have made positive contributions to the production of renewable energy and environmental protection. Today, farm biogas digesters are used to store gas from wastewater treatment plants. This biogas storage design has been tested and validated for decades and is now an integral feature of any modern sewage treatment plant design in the world.



Our farm biogas digester (also known as anaerobic digester) is made of glass cladding steel and is the top technology on the market. Glass fused to steel plates exhibits excellent chemical and physical properties due to the presence of titanium. In addition, the ultrafine glass foam structure of the enamel layer forms an inner layer of protection on the inner and outer tank surfaces to protect against inclement weather, corrosion and wear.



Farm Biogas Digester Specifications



Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet, around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,

salt fox, organic and inorganic compounds





Specification of the Farm Biogas Digesters



Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61, API and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 65 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
